– 13 –
PART LIST
PART # DESCRIPTION
61024-01 Blade lock nut
61024-02 Outer flange
6-1003Q Blade
61024-04 Inner flange
61024-05 Blade guard fixing knob
61024-06 Blade guard
61024-07 Water brush (2)
61024-08 Screw
61024-09 Flat washer
61024-10 Y-water feed
61024-11 Phillips screw M5X16
61024-12 Water tube splitter plate
61024-13 Splash guard
61024-14 Phillips screw M4X12 (8)
61024-15 Flat washer (8)
61024-16 Blade guard shaft
61024-17 Plunge adjusting lever
61024-18 Wave-shaped bushing
61024-19 Teeth-surface nut
61024-20 Flat washer
61024-21 Motor head handle
61024-22 Motor
61024-23 Switch
61024-24 Receptacle socket
61024-25 Power cord
61024-26 Bevel hinge shaft
61024-27 Plunge adjusting plate
61024-28 Screw (2)
61024-29 Washer plate (2)
61024-30 Spring washer (2)
61024-31 Motor frame
61024-32 Bearings (2)
61024-33 Plunge counterforce spring
61024-34 Plunge shaft
61024-35 Hex screw (2)
61024-36
Phillips screw (square neck)
M8X40
61024-37 Bevel angle marking plate
61024-38 Pointer
61024-39 Bevel cut adjustment knob
PART # DESCRIPTION
61024-40 Bevel hinge shaft
61024-41 Hex socket cap screw (3)
61024-42 Motor frame locking knob
61024-43 Cord collecting hanger
61024-44
Cord collecting hanger
cover plate
61024-45 Screw (2)
61024-46 Motor support arm
61024-47 Hex socket cap screw
61024-48 Lock nut (2)
61024-49 Flat washer (2)
61024-50 Spring washer (2)
61024-51 Hex screw (2)
61024-52
Hex socket cap screw
M10X12
61024-53 Motor support arm washer
61024-54 Hex screw (2)
61024-55 Teeth – surfaced washer (2)
61024-56 Flat washer (2)
61024-57 4 in. base frame caster (2)
61024-58 Hex screw (2)
61024-59 Self locking nut M8 (2)
61024-60 Base frame
61024-61 Working table sliding rail
61024-62 Slide tube assembly (2)
61024-63 Grease injection fitting
61024-64 Sliding tube locking knob
61024-65 Sliding tube
61024-66 Hex screw (2)
61024-67 Working table pad
61024-68 Overload switch
61024-69 Work table
61024-70 Back extension working table
61024-71 Pin (2)
61024-72
Back extension working
table pad
61024-73 Roller fixing plate
61024-74
Hex socket cap screw
M8X22 (4)
61024-75 Nylon roller (2)
61024-76 Flat washer (13)
PART # DESCRIPTION
61024-77 Hex screw (2)
61024-78
Side extension table tube
bushing (2)
61024-79 Side extension table tube (2)
61024-80
Hex socket cap screw
M5X10 (2)
61024-81 Side extension table
61024-82 Side extension table pad
61024-83 Water tray
61024-84 Tank drainage plug
61024-85 Phillips screw M6X20 (2)
61024-86 Stand knob (2)
61024-87 Saw stand
61024-88 Sliding tube end seal (2)
61024-89 Extension water tray
61024-90 Motor shaft wrench
61024-91 Wrench for loosening nut
61024-92 Allen wrench
60095 Water pump
61024-94 Rip guide
61024-95 Rip guide locking knob
61024-96 Spring washer (13)
61024-97 Self tapping screw (4)
61024-98 Motor shaft bushing
61024-99 Sealing
61024-100 Capacitor
61024-101 Thin nut (2)
61024-102 Flat washer
61024-103 Flat washer
61024-104 Water tube clip
