DETAILED COOLING CAPACITIES# (CONT.)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
114ANA024--- D Outdoor Section With CAP**2414A* Indoor Section
700
72 (22.2) 27.69 13.74 1.56 26.47 13.29 1.74 25.18 12.83 1.95 23.82 12.35 2.17 22.35 11.83 2.42 20.74 11.28 2.69 67 (19.4) 25.12 16.76 1.56 23.98 16.31 1.74 22.79 15.84 1.95 21.54 15.35 2.17 20.19 14.83 2.42 18.72 14.27 2.69
63 (17.2)†† 23.30 16.20 1.56 22.23 15.74 1.74 21.12 15.27 1.94 19.94 14.78 2.17 18.67 14.26 2.42 17.30 13.69 2.69
62 (16.7) 22.88 19.79 1.56 21.85 19.33 1.74 20.79 18.84 1.94 19.68 18.33 2.17 18.60 18.60 2.42 17.50 17.50 2.69 57 (13.9) 22.21 22.21 1.56 21.39 21.39 1.74 20.53 20.53 1.94 19.60 19.60 2.17 18.60 18.60 2.42 17.50 17.50 2.69
800
72 (22.2) 28.25 14.43 1.60 26.96 13.97 1.78 25.62 13.50 1.98 24.20 13.01 2.21 22.68 12.49 2.46 21.01 11.93 2.73 67 (19.4) 25.62 17.85 1.60 24.43 17.39 1.78 23.20 16.92 1.98 21.90 16.42 2.21 20.50 15.89 2.46 18.98 15.32 2.73
63 (17.2)†† 23.77 17.23 1.60 22.66 16.76 1.78 21.50 16.28 1.98 20.28 15.78 2.21 18.97 15.25 2.46 17.54 14.67 2.73
62 (16.7) 23.44 21.28 1.60 22.40 20.78 1.78 21.36 21.36 1.98 20.39 20.39 2.21 19.32 19.32 2.46 18.14 18.14 2.73 57 (13.9) 23.17 23.17 1.60 22.30 22.30 1.78 21.37 21.37 1.98 20.39 20.39 2.21 19.32 19.32 2.46 18.14 18.14 2.73
900
72 (22.2) 28.66 15.08 1.64 27.33 14.62 1.82 25.94 14.14 2.02 24.47 13.64 2.25 22.90 13.12 2.49 21.19 12.55 2.77 67 (19.4) 26.00 18.90 1.64 24.78 18.43 1.82 23.51 17.95 2.02 22.17 17.44 2.25 20.74 16.91 2.49 19.18 16.32 2.77
63 (17.2)†† 24.13 18.21 1.63 22.99 17.74 1.82 21.79 17.25 2.02 20.53 16.73 2.24 19.19 16.19 2.49 17.74 15.59 2.77
62 (16.7) 23.95 23.95 1.63 23.05 23.05 1.82 22.07 22.07 2.02 21.03 21.03 2.24 19.91 19.91 2.49 18.66 18.66 2.77 57 (13.9) 23.98 23.98 1.63 23.05 23.05 1.82 22.08 22.08 2.02 21.03 21.03 2.24 19.91 19.91 2.49 18.66 18.66 2.77
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
*CAP**2414A** 1.00 1.00
CAP**2417A** 1.00 1.00 CAP**3014A** 1.01 0.98 CAP**3017A** 1.01 0.98
CNPF*2418A** 1.00 1.00
CNPH*2417A** 1.00 1.00 CNPH*3017A** 1.01 0.98
CNPV*2414A** 1.00 1.00 CNPV*2417A** 1.00 1.00 CNPV*3014A** 1.01 0.98 CNPV*3017A** 1.01 0.98
CSPH*2412A** 1.00 1.00 CSPH*3012A** 1.01 0.98
FE4AN(B,F)003 1.02 0.90
FE4ANF002 1.01 0.89
FE5ANB004 1.04 0.92
FF1ENP024 0.99 0.99 FF1ENP030 0.99 0.99
FV4BN(B,F)003 1.02 0.90
FV4BNF002 1.01 0.89
FX4CNF024 1.01 0.94 FX4CNF030 1.02 0.92
FY4ANF024 0.99 1.02 FY4ANF030 1.00 0.98
CAP**2414A** 0.99 0.89 315(A,J)AV036070 CAP**3014A** 1.00 0.90 315(A,J)AV036070
CNPH*2417A** 0.98 0.88 315(A,J)AV036070 CNPH*3017A** 1.00 0.90 315(A,J)AV036070
CNPV*2414A** 0.98 0.88 315(A,J)AV036070 CNPV*3014A** 1.00 0.90 315(A,J)AV036070
CSPH*2412A** 0.99 0.89 315(A,J)AV036070 CSPH*3012A** 1.00 0.90 315(A,J)AV036070
CAP**2417A** 0.99 0.89 315(A,J)AV048090 CAP**3017A** 1.00 0.89 315(A,J)AV048090
CNPH*2417A** 0.99 0.89 315(A,J)AV048090 CNPH*3017A** 1.00 0.89 315(A,J)AV048090
CNPV*2417A** 0.99 0.89 315(A,J)AV048090 CNPV*3017A** 1.00 0.89 315(A,J)AV048090
CSPH*2412A** 0.99 0.89 315(A,J)AV048090
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CSPH*3012A** 1.00 0.89 315(A,J)AV048090
CNPH*2417A** 0.99 0.89 315(A,J)AV060110 CNPH*3017A** 1.00 0.90 315(A,J)AV060110
CSPH*2412A** 1.00 0.90 315(A,J)AV060110 CSPH*3012A** 1.01 0.91 315(A,J)AV060110
CNPH*2417A** 0.99 0.89 315(A,J)AV066135 CNPH*3017A** 1.01 0.91 315(A,J)AV066135
CSPH*2412A** 1.00 0.90 315(A,J)AV066135 CSPH*3012A** 1.01 0.91 315(A,J)AV066135
CNPH*2417A** 0.99 0.89 315(A,J)AV066155 CNPH*3017A** 1.01 0.89 315(A,J)AV066155
CSPH*2412A** 1.00 0.90 315(A,J)AV066155 CSPH*3012A** 1.01 0.91 315(A,J)AV066155
CAP**2417A** 1.00 0.90 353AAV036040 CAP**3017A** 1.00 0.90 353AAV036040
CNPH*2417A** 1.00 0.90 353AAV036040 CNPH*3017A** 1.00 0.90 353AAV036040
CNPV*2417A** 1.00 0.90 353AAV036040 CNPV*3017A** 1.00 0.90 353AAV036040
CSPH*2412A** 1.00 0.90 353AAV036040 CSPH*3012A** 1.00 0.90 353AAV036040
CAP**2417A** 1.00 0.90 353AAV036060 CAP**3017A** 1.00 0.90 353AAV036060
CNPH*2417A** 1.00 0.90 353AAV036060 CNPH*3017A** 1.00 0.90 353AAV036060
CNPV*2417A** 1.00 0.90 353AAV036060 CNPV*3017A** 1.00 0.90 353AAV036060
CSPH*2412A** 1.00 0.90 353AAV036060 CSPH*3012A** 1.00 0.90 353AAV036060
CAP**2417A** 1.00 0.90 353AAV036080 CAP**3017A** 1.00 0.90 353AAV036080
CNPH*2417A** 1.00 0.90 353AAV036080 CNPH*3017A** 1.00 0.90 353AAV036080
CNPV*2417A** 1.00 0.90 353AAV036080 CNPV*3017A** 1.00 0.90 353AAV036080
CSPH*2412A** 1.00 0.90 353AAV036080 CSPH*3012A** 1.00 0.90 353AAV036080
CNPH*2417A** 0.99 0.89 355(A,C)AV042040 CNPH*3017A** 1.00 0.90 355(A,C)AV042040
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CSPH*2412A** 1.00 0.90 355(A,C)AV042040 CSPH*3012A** 1.01 0.91 355(A,C)AV042040
CAP**2417A** 0.99 0.89 355(A,C)AV042060 CAP**3017A** 1.00 0.90 355(A,C)AV042060
CNPH*2417A** 0.99 0.89 355(A,C)AV042060 CNPH*3017A** 1.00 0.90 355(A,C)AV042060
CNPV*2417A** 0.99 0.89 355(A,C)AV042060 CNPV*3017A** 1.00 0.90 355(A,C)AV042060
CSPH*2412A** 0.99 0.89 355(A,C)AV042060 CSPH*3012A** 1.00 0.90 355(A,C)AV042060
CNPH*2417A** 0.99 0.89 355(A,C)AV042080 CNPH*3017A** 1.00 0.90 355(A,C)AV042080
CSPH*2412A** 1.00 0.90 355(A,C)AV042080 CSPH*3012A** 1.00 0.90 355(A,C)AV042080
CNPH*2417A** 0.98 0.92 355(A,C)AV060080 CNPH*3017A** 0.99 0.89 355(A,C)AV060080
CSPH*2412A** 0.99 0.89 355(A,C)AV060080 CSPH*3012A** 0.99 0.89 355(A,C)AV060080
CNPH*2417A** 0.99 0.89 355(A,C)AV060100 CNPH*3017A** 1.00 0.90 355(A,C)AV060100
CSPH*2412A** 1.00 0.90 355(A,C)AV060100 CSPH*3012A** 1.01 0.91 355(A,C)AV060100
CNPH*2417A** 0.98 0.92 355(A,C)AV060120 CNPH*3017A** 1.00 0.90 355(A,C)AV060120
CSPH*2412A** 1.00 0.90 355(A,C)AV060120 CSPH*3012A** 1.00 0.90 355(A,C)AV060120
CAP**2414A** 1.00 0.90 313*AV024045 CAP**3014A** 1.01 0.91 313*AV024045
CNPH*2417A** 0.99 0.93 313*AV024045 CNPH*3017A** 1.01 0.91 313*AV024045
CNPV*2414A** 0.99 0.93 313*AV024045 CNPV*3014A** 1.01 0.91 313*AV024045
CSPH*2412A** 0.99 0.93 313*AV024045 CSPH*3012A** 1.01 0.91 313*AV024045
See notes on pg. 32
