Bryant 114A Series User Manual

7
ELECTRICAL DATA
UNIT SIZE V/PH
OPER
VOLTS*
COMPR FAN
MCA
MIN WIRE
SIZE{
60° C
MIN WIRE
SIZE{
75° C
MAX
LENGTH
ft (m)}
60° C
MAX
LENGTH
ft (m)}
75° C
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
018--C
208/230/1--- 60 253 197
48.0 9.0 0.5 11.7 14 14 67 (20.4) 64 (19.5) 15
024--D 58.3 13.5 0.5 17.3 14 14 46 (14.0) 43 (13.1) 30
030--D 73.0 14.1 0.5 18.1 14 14 44 (13.4) 41 (12.5) 30
036--C 79.0 16.7 1.2 22.0 12 12 57 (17.4) 54 (16.5) 35
042--D 112.0 17.9 1.2 23.6 10 10 85 (26.0) 80 (24.4) 40
048--D 117.0 21.8 1.2 28.4 10 10 70 (21.3) 67 (20.4) 40
060--D 134.0 26.4 1.2 34.2 8 8 91 (27.7) 86 (26.2) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied a t ambient greater than 30° C (86° F), consult table 310---16 of the NE C ( ANSI/NFPA 70) . The ampacity of non ---metal lic---sheathed cable
(NM), trade name ROMEX, shall be that of 60° C conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated ( no---plated), 60 or 75° C
insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
} Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r Am p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
A--WEIGHTED SOUND POWER LEVEL (dBA)
UNIT SIZE --
SERIES
STANDARD RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018--C 76 56.0 60.0 65.0 72.0 65.0 60.5 53.5
024--D 76 50.5 61.5 68.0 67.5 64.0 60.0 53.5
030--D 76 52.0 62.5 71.0 69.0 65.0 62.0 59.5
036--C 76 52.0 60.0 65.5 69.5 64.0 63.0 56.0
042--D 77 55.0 62.0 66.0 70.5 65.5 60.0 54.0
048--D 78 51.5 62.0 67.5 73.5 69.0 64.5 62.0
060--D 78 57.0 62.5 69.0 73.0 66.0 62.0 57.5
NOTE: Tested in accordance with ARI Standard 270 ---95 (not listed in ARI).
A--WEIGHTED SOUND POWER LEVEL (dBA) WITH ACCESSORY SOUND HOOD
UNIT SIZE --
SERIES
STANDARD RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018--C 74 56.0 60.0 65.0 69.0 63.0 60.0 52.5
024--D 74 51.5 61.0 67.5 66.5 63.0 59.0 51.5
030--D 74 53.0 62.0 68.5 68.0 64.5 61.0 56.0
036--C 75 52.0 62.0 65.5 67.5 63.0 61.0 53.5
042--D 74 55.0 61.5 65.0 68.5 65.0 59.0 52.0
048--D 76 53.0 61.5 67.5 72.0 68.0 61.5 59.0
060--D 75 57.0 62.5 68.5 71.0 65.0 60.5 58.5
NOTE: Tested in accordance with ARI Standard 270 ---95 (not listed in ARI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- SERIES REQUIRED SUBCOOLING _F(_C)
018---C 10 (5.6)
024---D 10 (5.6)
030---D 11 (6.1)
036---C 10 (5.6)
042---D 8 (4.4)
048---D 8 (4.4)
060---D 9 (5.0)
114A
