Bryant 114A Series User Manual

33
CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
114ANA018--- C
30
( ---1.11)
TCG 16.80 15.70 14.70 13.80 12.80 11.80 10.80 9.70
SDT 66.70 76.10 85.40 94.80 104.30 113.70 123.20 132.70
KW 0.78 0.90 1.03 1.18 1.34 1.53 1.72 1.94
35
(1.67)
TCG 18.60 17.40 16.40 15.30 14.20 13.20 12.00 10.90
SDT 67.90 77.10 86.40 95.80 105.10 114.50 124.00 133.40
KW 0.77 0.89 1.02 1.17 1.34 1.52 1.72 1.94
40
(4.44)
TCG 20.50 19.30 18.10 16.90 15.80 14.60 13.40 12.10
SDT 69.10 78.30 87.50 96.80 106.10 115.40 124.80 134.10
KW 0.76 0.88 1.01 1.16 1.33 1.51 1.72 1.94
45
(7.22)
TCG 22.60 21.30 20.00 18.70 17.40 16.10 14.80 13.40
SDT 70.40 79.50 88.60 97.80 107.00 116.30 125.60 134.90
KW 0.74 0.86 1.00 1.15 1.32 1.50 1.71 1.94
50
(10.0)
TCG 24.80 23.40 22.00 20.60 19.20 17.80 16.30 14.80
SDT 71.80 80.70 89.80 98.90 108.00 117.20 126.40 135.60
KW 0.73 0.85 0.99 1.14 1.31 1.49 1.70 1.93
55
(12.78)
TCG 27.20 25.60 24.10 22.50 21.00 19.40 17.90 33.70
SDT 73.20 82.10 91.00 100.10 109.10 118.20 127.30 130.60
KW 0.72 0.84 0.98 1.13 1.30 1.48 1.69 1.77
114ANA024--- D
30
( ---1.11)
TCG 20.90 19.70 18.60 17.40 16.20 15.00 13.70 12.40
SDT 66.60 76.10 85.60 95.10 104.70 114.20 123.80 133.40
KW 0.99 1.14 1.30 1.48 1.68 1.90 2.14 2.40
35
(1.67)
TCG 23.00 21.80 20.60 19.30 18.00 16.70 15.30 13.80
SDT 67.70 77.10 86.60 96.00 105.50 115.00 124.60 134.10
KW 1.00 1.14 1.30 1.48 1.68 1.90 2.15 2.41
40
(4.44)
TCG 25.40 24.00 22.70 21.30 19.90 18.50 17.00 15.40
SDT 68.80 78.20 87.60 97.00 106.40 115.80 125.30 134.80
KW 1.00 1.14 1.30 1.48 1.69 1.91 2.15 2.42
45
(7.22)
TCG 27.80 26.40 24.90 23.50 22.00 20.40 18.80 17.10
SDT 70.00 79.30 88.60 98.00 107.30 116.70 126.10 135.60
KW 1.00 1.14 1.31 1.49 1.69 1.91 2.15 2.42
50
(10.0)
TCG 30.50 29.00 27.40 25.80 24.20 22.50 20.80 18.90
SDT 71.30 80.50 89.80 99.00 108.30 117.60 127.00 136.30
KW 1.00 1.15 1.31 1.49 1.69 1.91 2.16 2.43
55
(12.78)
TCG 33.40 31.70 30.00 28.30 26.50 24.70 22.90 20.90
SDT 72.60 81.80 90.90 100.10 109.30 118.60 127.80 137.10
KW 1.01 1.15 1.31 1.49 1.69 1.92 2.16 2.43
114ANA030--- D
30
( ---1.11)
TCG 27.40 25.90 24.50 22.90 21.30 19.70 18.00 16.20
SDT 68.50 77.80 87.20 96.60 106.00 115.40 124.90 134.30
KW 1.25 1.43 1.63 1.85 2.09 2.35 2.63 2.93
35
(1.67)
TCG 30.20 28.60 27.00 25.30 23.60 21.90 20.00 18.00
SDT 69.70 78.90 88.30 97.60 106.90 116.30 125.70 135.00
KW 1.26 1.43 1.63 1.85 2.10 2.36 2.65 2.95
40
(4.44)
TCG 33.10 31.40 29.70 27.90 26.00 24.10 22.20 20.10
SDT 70.90 80.10 89.40 98.60 107.90 117.20 126.50 135.80
KW 1.26 1.44 1.64 1.86 2.10 2.37 2.66 2.97
45
(7.22)
TCG 36.20 34.40 32.50 30.60 28.60 26.50 24.40 22.10
SDT 72.20 81.30 90.50 99.70 108.90 118.20 127.40 136.60
KW 1.27 1.44 1.64 1.86 2.11 2.38 2.67 2.98
50
(10.0)
TCG 39.60 37.60 35.50 33.40 31.20 29.00 26.70 24.20
SDT 73.60 82.60 91.70 100.90 110.00 119.20 128.30 137.40
KW 1.27 1.45 1.65 1.87 2.12 2.39 2.68 3.00
55
(12.78)
TCG 43.00 40.80 38.60 36.30 33.90 31.50 29.00 26.40
SDT 75.00 84.00 93.00 102.00 111.10 120.20 129.20 138.20
KW 1.28 1.46 1.66 1.88 2.12 2.39 2.69 3.00
114ANA036--- C
30
( ---1.11)
TCG 33.70 31.90 30.00 28.00 26.00 23.90 21.70 19.40
SDT 72.00 81.70 91.30 101.00 110.70 120.50 130.40 140.60
KW 1.50 1.71 1.94 2.20 2.48 2.79 3.11 3.46
35
(1.67)
TCG 37.10 35.20 33.10 31.10 28.90 26.70 24.30 21.80
SDT 73.40 83.00 92.60 102.20 111.90 121.70 131.60 141.70
KW 1.51 1.72 1.96 2.22 2.50 2.81 3.15 3.52
40
(4.44)
TCG 40.90 38.70 36.60 34.30 32.00 29.60 27.10 24.40
SDT 74.60 84.30 93.90 103.50 113.10 122.90 132.70 142.80
KW 1.52 1.74 1.97 2.23 2.52 2.84 3.19 3.56
45
(7.22)
TCG 44.80 42.50 40.20 37.80 35.40 32.80 30.10 27.20
SDT 76.00 85.70 95.30 104.80 114.40 124.00 133.80 143.80
KW 1.53 1.75 1.99 2.25 2.54 2.86 3.22 3.60
50
(10.0)
TCG 49.10 46.70 44.20 41.60 39.00 36.20 33.30 30.20
SDT 77.30 87.00 96.70 106.10 115.60 125.20 134.90 144.80
KW 1.54 1.76 2.00 2.27 2.56 2.88 3.24 3.63
55
(12.78)
TCG 53.70 51.10 48.40 45.60 42.80 39.80 36.70 33.40
SDT 78.60 88.40 98.00 107.50 116.90 126.50 136.00 145.70
KW 1.55 1.77 2.02 2.28 2.58 2.90 3.26 3.66
See n otes on page 34
114A
