CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
114ANA042--- C
30
( ---1.11)
TCG 37.40 35.70 33.80 31.80 29.70 27.40 25.00 22.50
SDT 68.10 77.60 87.00 96.40 105.80 115.20 124.60 133.90
KW 1.78 1.96 2.18 2.43 2.72 3.06 3.44 3.86
35
(1.67)
TCG 41.30 39.40 37.40 35.10 32.80 30.30 27.70 25.00
SDT 69.40 78.80 88.10 97.50 106.90 116.20 125.40 134.70
KW 1.79 1.97 2.19 2.44 2.74 3.07 3.45 3.87
40
(4.44)
TCG 45.60 43.40 41.10 38.70 36.10 33.40 30.60 27.60
SDT 70.80 80.10 89.40 98.60 107.90 117.20 126.40 135.50
KW 1.80 1.98 2.20 2.46 2.75 3.09 3.47 3.89
45
(7.22)
TCG 50.10 47.70 45.20 42.50 39.70 36.70 33.60 30.30
SDT 72.30 81.40 90.60 99.80 109.00 118.20 127.30 136.30
KW 1.81 2.00 2.22 2.48 2.78 3.11 3.49 3.91
50
(10.0)
TCG 55.00 52.30 49.40 46.50 43.40 40.10 36.70 33.10
SDT 73.80 82.90 92.00 101.10 110.20 119.30 128.30 137.20
KW 1.82 2.01 2.24 2.50 2.80 3.14 3.51 3.93
55
(12.78)
TCG 60.10 57.10 53.90 50.70 47.30 43.70 40.00 36.10
SDT 75.40 84.40 93.40 102.40 111.40 120.40 129.30 138.10
KW 1.82 2.03 2.26 2.52 2.83 3.16 3.54 3.96
114ANA048--- D
30
( ---1.11)
TCG 45.00 42.40 39.90 37.40 34.90 32.30 29.50 26.40
SDT 70.30 79.50 88.90 98.20 107.60 116.90 126.20 135.40
KW 2.04 2.41 2.75 3.08 3.44 3.84 4.32 4.89
35
(1.67)
TCG 49.80 46.80 44.00 41.20 38.50 35.60 32.60 29.30
SDT 71.70 80.90 90.10 99.40 108.70 118.00 127.20 136.30
KW 1.99 2.39 2.75 3.10 3.47 3.87 4.34 4.90
40
(4.44)
TCG 54.90 51.50 48.40 45.30 42.20 39.10 35.80 32.30
SDT 73.20 82.40 91.50 100.70 109.90 119.00 128.20 137.20
KW 1.93 2.36 2.75 3.12 3.50 3.91 4.38 4.92
45
(7.22)
TCG 60.40 56.60 53.00 49.60 46.20 42.80 39.30 35.50
SDT 74.80 83.90 92.90 102.00 111.10 120.20 129.20 138.10
KW 1.86 2.33 2.75 3.14 3.53 3.95 4.41 4.94
50
(10.0)
TCG 66.20 62.00 58.00 54.20 50.50 46.70 42.90 38.70
SDT 76.40 85.50 94.50 103.40 112.40 121.40 130.30 139.10
KW 1.78 2.28 2.73 3.15 3.56 3.99 4.45 4.98
55
(12.78)
TCG 72.40 67.70 63.20 59.10 55.00 50.90 46.70 42.10
SDT 78.20 87.10 96.10 104.90 113.80 122.60 131.40 140.10
KW 1.68 2.23 2.71 3.16 3.59 4.02 4.49 5.01
114ANA060--- D
30
( ---1.11)
TCG 54.80 52.00 49.20 46.20 43.10 39.90 36.40 32.70
SDT 72.60 81.60 90.60 99.70 108.80 117.90 126.90 135.90
KW 2.54 2.85 3.18 3.55 3.97 4.45 5.01 5.67
35
(1.67)
TCG 60.40 57.30 54.20 50.90 47.60 44.00 40.20 36.20
SDT 74.40 83.20 92.10 101.10 110.10 119.10 128.00 136.90
KW 2.58 2.89 3.22 3.59 4.01 4.50 5.06 5.70
40
(4.44)
TCG 66.40 63.00 59.50 56.00 52.30 48.40 44.30 39.80
SDT 76.20 84.90 93.80 102.60 111.50 120.40 129.20 138.00
KW 2.63 2.94 3.28 3.65 4.07 4.55 5.11 5.74
45
(7.22)
TCG 72.90 69.10 65.20 61.30 57.30 53.00 48.50 43.60
SDT 78.20 86.80 95.50 104.20 113.00 121.70 130.40 139.10
KW 2.69 3.00 3.34 3.71 4.13 4.61 5.16 5.79
50
(10.0)
TCG 79.70 75.50 71.30 67.00 62.50 57.90 52.90 47.60
SDT 80.30 88.70 97.20 105.90 114.50 123.10 131.70 140.20
KW 2.75 3.07 3.41 3.78 4.20 4.68 5.22 5.84
55
(12.78)
TCG 87.00 82.40 77.70 73.00 68.10 63.00 57.50 51.70
SDT 82.50 90.80 99.20 107.60 116.10 124.60 133.10 141.40
KW 2.83 3.15 3.49 3.86 4.28 4.75 5.29 5.90
* ARI listing applies onl y to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor ° F
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross C ooling Capacity (1000 Btuh)
