DETAILED COOLING CAPACITIES# (CONT.)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
114ANA036--- C Outdoor Section With CAP**4221A** Indoor Section
1050
72 (22.2) 42.83 21.41 2.35 40.92 20.71 2.63 38.92 19.98 2.94 36.78 19.21 3.29 34.47 18.40 3.68 31.94 17.51 4.12 67 (19.4) 38.83 26.08 2.35 37.06 25.37 2.63 35.20 24.62 2.94 33.22 23.84 3.29 31.08 23.01 3.68 28.75 22.11 4.12
63 (17.2)†† 35.91 25.16 2.35 34.27 24.45 2.63 32.54 23.71 2.94 30.68 22.92 3.28 28.68 22.09 3.67 26.48 21.18 4.10
62 (16.7) 35.34 30.76 2.35 33.74 30.03 2.63 32.07 29.26 2.94 30.32 28.42 3.29 28.58 28.58 3.68 26.83 26.83 4.12 57 (13.9) 34.26 34.26 2.35 32.98 32.98 2.63 31.63 31.63 2.94 30.17 30.17 3.29 28.58 28.58 3.68 26.83 26.83 4.12
1200
72 (22.2) 43.66 22.44 2.40 41.67 21.72 2.68 39.58 20.98 2.99 37.36 20.20 3.34 34.96 19.37 3.73 32.33 18.47 4.17 67 (19.4) 39.58 27.71 2.40 37.74 26.98 2.68 35.80 26.22 2.99 33.75 25.43 3.34 31.55 24.59 3.73 29.14 23.68 4.17
63 (17.2)†† 36.60 26.68 2.41 34.89 25.95 2.69 33.09 25.20 2.99 31.17 24.41 3.34 29.11 23.56 3.72 26.85 22.63 4.15
62 (16.7) 36.18 32.98 2.40 34.56 32.21 2.68 32.87 32.87 2.99 31.35 31.35 3.34 29.67 29.67 3.73 27.80 27.80 4.17 57 (13.9) 35.72 35.72 2.40 34.36 34.36 2.68 32.91 32.91 2.99 31.36 31.36 3.34 29.67 29.67 3.73 27.80 27.80 4.17
1350
72 (22.2) 44.27 23.39 2.45 42.22 22.67 2.73 40.06 21.92 3.05 37.77 21.13 3.40 35.31 20.29 3.79 32.61 19.38 4.22 67 (19.4) 40.14 29.23 2.45 38.24 28.50 2.73 36.25 27.74 3.04 34.15 26.94 3.39 31.89 26.09 3.78 29.44 25.15 4.22
63 (17.2)†† 37.12 28.10 2.46 35.36 27.38 2.74 33.51 26.62 3.05 31.55 25.81 3.39 29.44 24.95 3.77 27.14 23.99 4.21
62 (16.7) 36.97 34.99 2.45 35.49 35.49 2.73 33.97 33.97 3.04 32.33 32.33 3.39 30.56 30.56 3.78 28.59 28.59 4.22 57 (13.9) 36.94 36.94 2.45 35.50 35.50 2.73 33.97 33.97 3.04 32.34 32.34 3.39 30.56 30.56 3.78 28.60 28.60 4.22
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**4221A** 1.00 1.00
CAP**3614A** 0.96 0.96 CAP**3617A** 0.99 1.03 CAP**3621A** 0.99 1.03 CAP**4224A** 1.00 1.00
CNPF*3618A** 0.99 1.03
CNPH*3617A** 0.99 1.03 CNPH*4221A** 1.00 1.00
CNPV*3617A** 0.99 1.03 CNPV*3621A** 0.99 1.03 CNPV*4217A** 1.00 1.00 CNPV*4221A** 1.00 1.00
CSPH*3612A** 0.98 0.94 CSPH*4212A** 1.00 1.00
FF1ENP036 0.98 0.98
FV4BN(B,F)003 0.99 0.91 FV4BN(B,F)005 1.02 0.94
FV4BNB006 1.03 0.92
FV4BNF002 0.98 0.94
FX4CN(B,F)036 1.01 0.97 FX4CN(B,F)042 1.02 0.94
FY4ANF036 0.97 1.01 FY4ANF042 1.01 1.05
CAP**3614A** 0.95 0.91 315(A,J)AV036070
CNPH*3617A** 0.98 0.94 315(A ,J)AV036070 CNPH*4221A** 0.99 0.91 315(A ,J)AV036070
CSPH*3612A** 0.98 0.98 315(A,J)AV036070 CSPH*4212A** 0.99 0.95 315(A,J)AV036070
CAP**3617A** 0.98 0.94 315(A,J)AV048090
CNPV*3617A** 0.98 0.94 315(A ,J)AV048090 CNPV*4217A** 0.98 0.92 315(A ,J)AV048090
CAP**3621A** 0.98 0.91 315(A,J)AV060110 CAP**4221A** 0.99 0.91 315(A,J)AV060110
CNPV*3621A** 0.98 0.94 315(A ,J)AV060110
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*4221A** 0.99 0.91 315(A ,J)AV060110
CAP**4224A** 0.99 0.91 315(A,J)AV066135
CNPH*4221A** 0.99 0.92 315(A ,J)AV066135 CNPH*4221A** 0.99 0.92 315(A ,J)AV066155
CAP**3617A** 0.98 0.92 353AAV036040
CNPH*3617A** 0.98 0.92 353AAV036040 CNPH*4221A** 0.98 0.92 353AAV036040
CNPV*3617A** 0.98 0.92 353AAV036040 CNPV*4217A** 0.98 0.92 353AAV036040
CSPH*3612A** 0.98 0.92 353AAV036040 CSPH*4212A** 0.98 0.92 353AAV036040
CAP**3617A** 0.98 0.92 353AAV036060
CNPH*3617A** 0.98 0.92 353AAV036060 CNPH*4221A** 0.98 0.92 353AAV036060
CNPV*3617A** 0.98 0.92 353AAV036060 CNPV*4217A** 0.98 0.92 353AAV036060
CSPH*3612A** 0.98 0.92 353AAV036060 CSPH*4212A** 0.98 0.92 353AAV036060
CAP**3617A** 0.98 0.92 353AAV036080
CNPH*3617A** 0.98 0.92 353AAV036080 CNPH*4221A** 0.98 0.92 353AAV036080
CNPV*3617A** 0.98 0.92 353AAV036080 CNPV*4217A** 0.98 0.92 353AAV036080
CSPH*3612A** 0.98 0.92 353AAV036080 CSPH*4212A** 0.98 0.92 353AAV036080
CAP**3617A** 0.98 0.92 353AAV048080
CNPH*3617A** 0.98 0.92 353AAV048080 CNPH*4221A** 0.98 0.92 353AAV048080
CNPV*3617A** 0.98 0.92 353AAV048080 CNPV*4217A** 0.98 0.92 353AAV048080
CSPH*3612A** 0.98 0.92 353AAV048080 CSPH*4212A** 0.98 0.92 353AAV048080
CAP**3621A** 0.98 0.92 353AAV060100 CAP**4221A** 0.98 0.92 353AAV060100
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*3617A** 0.98 0.92 353AAV060100 CNPH*4221A** 0.98 0.92 353AAV060100
CNPV*3621A** 0.98 0.92 353AAV060100 CNPV*4221A** 0.98 0.92 353AAV060100
CSPH*3612A** 0.98 0.92 353AAV060100 CSPH*4212A** 0.98 0.92 353AAV060100
CAP**4224A** 0.98 0.94 355(A,C)AV042040
CNPH*3617A** 0.98 0.94 355(A,C)AV042040 CNPH*4221A** 0.98 0.91 355(A,C)AV042040
CSPH*3612A** 0.98 0.94 355(A,C)AV042040 CSPH*4212A** 0.98 0.94 355(A,C)AV042040
CAP**3617A** 0.98 0.94 355(A,C)AV042060
CNPH*4221A** 0.99 0.91 355(A,C)AV042060
CNPV*3617A** 0.98 0.94 355(A,C)AV042060 CNPV*4217A** 0.98 0.92 355(A,C)AV042060
CAP**3621A** 0.98 0.94 355(A,C)AV042080 CAP**4221A** 0.98 0.94 355(A,C)AV042080
CNPV*3621A** 0.98 0.94 355(A,C)AV042080 CNPV*4221A** 0.99 0.91 355(A,C)AV042080
CAP**3621A** 0.98 0.94 355(A,C)AV060080 CAP**4221A** 0.99 0.95 355(A,C)AV060080 CAP**3621A** 0.98 0.91 355(A,C)AV060100 CAP**4221A** 0.99 0.95 355(A,C)AV060100
CNPV*3621A** 0.98 0.94 355(A,C)AV060100
CAP**4224A** 0.99 0.91 355(A,C)AV060120
CSPH*4212A** 0.99 0.95 355(A,C)AV060120
CAP**3614A** 0.96 0.92 313*AV024045
CNPH*3617A** 0.98 0.94 313*AV024045 CNPH*4221A** 0.99 0.95 313*AV024045
CSPH*3612A** 0.98 0.94 313*AV024045 CSPH*4212A** 0.99 0.95 313*AV024045
CAP**3617A** 0.98 0.93 313*AV048070
CNPH*3617A** 0.98 0.92 313*AV048070
