19
CONDENSER ONLY RATINGS* (CONTINUED)
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
180BNA060****A HI
30
(---1.11)
TCG 48.10 46.80 45.30 43.60 41.60 39.30 36.80 33.90
SDT 68.50 77.80 87.40 96.80 106.20 115.60 124.90 134.20
KW 2.43 2.80 3.18 3.57 3.99 4.44 4.94 5.48
35
(1.67)
TCG 54.10 52.80 51.20 49.40 47.30 44.80 42.10 38.90
SDT 69.70 79.10 88.50 97.90 107.30 116.50 125.80 135.00
KW 2.49 2.86 3.23 3.63 4.05 4.50 5.00 5.55
40
(4.44)
TCG 59.80 58.40 56.60 54.60 52.30 49.60 46.60 43.10
SDT 71.10 80.40 89.70 99.00 108.30 117.60 126.70 135.90
KW 2.55 2.91 3.29 3.68 4.11 4.56 5.07 5.62
45
(7.22)
TCG 65.80 64.20 62.30 60.10 57.60 54.50 51.30 47.50
SDT 72.60 81.80 91.00 100.30 109.50 118.60 127.70 136.80
KW 2.62 2.98 3.35 3.75 4.17 4.62 5.13 5.69
50
(10.0)
TCG 72.00 70.30 68.20 65.80 63.00 59.80 56.20 52.10
SDT 74.20 83.30 92.40 101.60 110.70 119.80 128.80 137.80
KW 2.70 3.05 3.42 3.81 4.24 4.70 5.21 5.77
55
(12.78)
TCG 78.20 76.40 74.10 71.50 68.40 65.00 61.10 56.60
SDT 75.80 84.90 93.90 103.00 112.00 121.00 129.90 138.80
KW 2.78 3.13 3.50 3.89 4.31 4.78 5.28 5.84
60
(15.56)
TCG 84.80 82.80 80.30 77.40 74.00 70.20 66.00 61.20
SDT 77.60 86.50 95.50 104.50 113.40 122.30 131.10 139.90
KW 2.87 3.22 3.59 3.98 4.40 4.86 5.37 5.93
180BNA060****A LOW
30
(---1.11)
TCG 33.20 32.20 30.90 29.40 27.70 25.80 23.80 21.60
SDT 66.20 75.90 85.50 95.10 104.60 114.10 123.60 133.10
KW 1.66 1.98 2.31 2.67 3.07 3.53 4.07 4.70
35
(1.67)
TCG 37.20 36.00 34.60 33.00 31.10 29.10 26.90 24.50
SDT 67.50 77.10 86.70 96.20 105.70 115.10 124.50 134.00
KW 1.66 1.97 2.29 2.64 3.04 3.49 4.02 4.64
40
(4.44)
TCG 41.60 40.20 38.60 36.80 34.80 32.60 30.30 27.70
SDT 68.80 78.40 87.90 97.30 106.70 116.10 125.50 134.90
KW 1.66 1.96 2.28 2.62 3.01 3.45 3.97 4.58
45
(7.22)
TCG 46.20 44.80 43.00 41.10 38.90 36.50 34.00 31.20
SDT 70.30 79.70 89.20 98.50 107.90 117.20 126.50 135.80
KW 1.66 1.96 2.26 2.60 2.98 3.41 3.92 4.52
50
(10.0)
TCG 51.30 49.70 47.80 45.60 43.30 40.70 38.00 35.00
SDT 71.80 81.20 90.50 99.80 109.10 118.30 127.50 136.70
KW 1.67 1.96 2.26 2.58 2.95 3.38 3.88 4.47
55
(12.78)
TCG 56.70 54.90 52.90 50.60 48.00 45.30 42.30 39.10
SDT 73.40 82.70 92.00 101.20 110.40 119.50 128.60 137.70
KW 1.68 1.96 2.25 2.57 2.93 3.35 3.84 4.41
60
(15.56)
TCG 62.60 60.60 58.40 55.90 53.10 50.10 46.90 43.40
SDT 75.20 84.30 93.50 102.60 111.70 120.70 129.80 138.80
KW 1.70 1.97 2.25 2.56 2.91 3.32 3.80 4.36
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F/° C)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Capacity (1000 B tuh)
180B
