17
CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
180BNA024****A HI
30
(---1.11)
TCG 22.50 21.30 20.20 18.90 17.60 16.30 14.90 13.40
SDT 67.50 77.40 87.20 97.00 106.80 116.70 126.60 136.70
KW 1.00 1.16 1.33 1.50 1.69 1.91 2.15 2.44
35
(1.67)
TCG 24.90 23.60 22.30 20.90 19.50 18.10 16.50 15.00
SDT 68.70 78.50 88.20 98.00 107.80 117.60 127.50 137.60
KW 1.02 1.18 1.35 1.52 1.72 1.93 2.18 2.47
40
(4.44)
TCG 27.40 26.00 24.60 23.10 21.50 20.00 18.30 16.60
SDT 70.00 79.70 89.40 99.10 108.80 118.50 128.40 138.50
KW 1.05 1.20 1.37 1.55 1.74 1.96 2.21 2.50
45
(7.22)
TCG 30.10 28.60 27.00 25.40 23.70 22.00 20.30 18.50
SDT 71.30 80.90 90.50 100.20 109.80 119.60 129.40 139.40
KW 1.07 1.23 1.39 1.57 1.76 1.99 2.24 2.53
50
(10.0)
TCG 33.10 31.40 29.70 27.90 26.10 24.20 22.40 20.40
SDT 72.60 82.10 91.70 101.30 111.00 120.60 130.40 140.40
KW 1.09 1.25 1.41 1.59 1.79 2.01 2.27 2.57
55
(12.78)
TCG 36.20 34.40 32.50 30.60 28.60 26.60 24.60 22.50
SDT 74.00 83.50 93.00 102.50 112.10 121.80 131.50 141.40
KW 1.12 1.28 1.44 1.62 1.82 2.04 2.30 2.61
60
(15.56)
TCG 39.60 37.60 35.50 33.50 31.30 29.20 27.00 24.70
SDT 75.50 84.90 94.30 103.80 113.40 122.90 132.60 142.40
KW 1.15 1.31 1.47 1.65 1.85 2.08 2.34 2.64
180BNA024****A LOW
30
(---1.11)
TCG 13.40 13.10 12.80 12.30 11.70 11.00 10.20 9.20
SDT 61.90 71.70 81.50 91.20 101.00 110.70 120.40 130.10
KW 0.58 0.71 0.84 0.99 1.14 1.31 1.52 1.75
35
(1.67)
TCG 15.20 14.90 14.50 13.90 13.30 12.60 11.70 10.70
SDT 62.80 72.60 82.30 92.00 101.70 111.40 121.00 130.70
KW 0.59 0.72 0.86 1.00 1.15 1.33 1.53 1.77
40
(4.44)
TCG 17.10 16.70 16.30 15.80 15.10 14.30 13.30 12.20
SDT 63.70 73.50 83.20 92.90 102.50 112.20 121.80 131.40
KW 0.61 0.74 0.87 1.01 1.16 1.34 1.54 1.78
45
(7.22)
TCG 19.10 18.80 18.30 17.70 17.00 16.10 15.10 13.90
SDT 64.70 74.40 84.10 93.80 103.40 113.00 122.60 132.10
KW 0.62 0.75 0.88 1.02 1.18 1.35 1.56 1.79
50
(10.0)
TCG 21.40 21.00 20.50 19.90 19.10 18.10 17.10 15.80
SDT 65.80 75.50 85.10 94.70 104.30 113.80 123.40 132.90
KW 0.65 0.77 0.90 1.04 1.19 1.37 1.57 1.80
55
(12.78)
TCG 23.80 23.40 22.80 22.20 21.30 20.30 19.20 17.80
SDT 66.90 76.60 86.10 95.70 105.20 114.80 124.20 133.70
KW 0.67 0.79 0.92 1.05 1.20 1.38 1.58 1.82
60
(15.56)
TCG 26.30 25.90 25.40 24.60 23.70 22.70 21.40 20.00
SDT 68.10 77.70 87.30 96.80 106.30 115.70 125.20 134.60
KW 0.70 0.81 0.94 1.07 1.22 1.39 1.60 1.83
180BNA036****B HI
30
(---1.11)
TCG 29.00 28.10 27.00 25.80 24.50 23.10 21.50 19.70
SDT 67.10 76.70 86.20 95.70 105.20 114.60 124.10 133.50
KW 1.38 1.58 1.80 2.02 2.26 2.52 2.81 3.14
35
(1.67)
TCG 32.20 31.20 30.10 28.80 27.40 25.80 24.10 22.30
SDT 68.40 77.90 87.30 96.80 106.20 115.60 125.00 134.40
KW 1.41 1.61 1.82 2.05 2.29 2.55 2.85 3.18
40
(4.44)
TCG 35.70 34.60 33.40 32.00 30.50 28.90 27.00 25.10
SDT 69.80 79.20 88.60 98.00 107.30 116.70 126.00 135.30
KW 1.44 1.64 1.86 2.08 2.32 2.59 2.89 3.22
45
(7.22)
TCG 39.40 38.30 37.00 35.50 33.90 32.10 30.20 28.10
SDT 71.20 80.50 89.90 99.20 108.50 117.80 127.00 136.30
KW 1.48 1.68 1.89 2.11 2.36 2.63 2.93 3.27
50
(10.0)
TCG 43.50 42.20 40.80 39.20 37.50 35.60 33.60 31.30
SDT 72.70 82.00 91.30 100.50 109.80 119.00 128.10 137.30
KW 1.52 1.72 1.93 2.15 2.40 2.67 2.97 3.31
55
(12.78)
TCG 47.80 46.40 44.90 43.30 41.40 39.40 37.20 34.80
SDT 74.30 83.50 92.70 101.90 111.10 120.20 129.30 138.40
KW 1.56 1.76 1.97 2.19 2.44 2.71 3.02 3.36
60
(15.56)
TCG 52.30 50.90 49.30 47.50 45.60 43.40 41.10 38.50
SDT 76.00 85.10 94.20 103.30 112.40 121.40 130.40 139.40
KW 1.61 1.81 2.02 2.24 2.49 2.76 3.07 3.41
See notes on page 19
