Bryant 284ANV - Control Board Diagrams and Indicators; Variable Speed and Primary Control Boards

284ANV: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
13
A200049
Fig. 25 – Variable Speed Control Board with optional Utility Relay
A200044
Fig. 26 – Primary Control Board
Status LED
(Yellow)
CCN Communication
LED (Green)
VFD LED (Red / Green)
VFD-PCM
Communication Port
