Bryant 286BNC User Manual

2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78910 11 12 14
N N N A A/N N N N N A/N A/N N A
28 6 B N C 0360 0 0 A
Product
Family
Tier SEER Major
Series
Voltage Variations Cooling Capacity Open Open Open Series
2=HP 8=
Evolution
Series
6 = 16 SEER B=Puron N= 208--- 230 ---1
or 208/230---1
C=Coastal 0=Not
Defined
0=Not
Defined
0=Not
Defined
A=
Original
Series
the environmentally sound refrigerant
This product has been designed and manufactured to
meet Energy Star® criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency a nd short en equipment l ife.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
This product has been designed and manufactured to
meet Energy Star® criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency a nd short en equipment l ife.
STANDARD FEATURES
FEATURES
Unit Size --- Voltage, Series
024---A 036---A 048---A 060---A
TuffCoat™ Fins X X X X
Inner and O uter Sheet Metal Surfaces Coated with Baked
on Powder Paint
X X X X
Puron Refrigerant X X X X
Maximum SEER Rating* 16.5 17.0 16.3 15.8
2--- Stage Scroll Compressor X X X X
Louvered Coil Guard X X X X
FieldInstalledFilterDrier X X X X
Front Seating Service Valves X X X X
Internal Pressure Relief Valve X X X X
Long Line capability X X X X
Loss of Charge Switch X X X X
High Pressure Switch X X X X
Crankcase Heater X X X X
Low ambient cooling down to 0_F capability
with Evolution Control
X X X X
Utility Interface Connections X X X X
Enhanced Diagnostics with Evolution C ontrol X X X X
Sound Blanket X X X X
* With approved combinations
X=Standard
286BNC

Bryant 286BNC Specifications

General

Brand	Bryant
Model	286BNC
Category	Heat Pump
Language	English
