7
Fig. 13 — Connect 48TMHSRSE--A20 Harness to
Harness from Controller
(Some control box configurations may differ)
Fig. 14 — Route 48TMHSRSE--A20 Harness to Indoor
Blower Section
Fig. 15 — Mount and Connect Mixed Air Sensor
Fig. 16 — Connect Pink and Violet Wires in Indoor
Blower Section
4-pin Male Plug
From Controller
48TMHSRSE--A20
Harness
Control
Box
48TMHSRSE--A20
Harness
Indoor
Blower
Section
Brown and Orange wires from
48TMHSRSE--A20 Harness
Indoor
Blower
Mixed Air
Temperature
Sensor
50HE403589
2-Green Wire
Harness
Pink and Violet
Wires from
48TMHSRSE--A20
Harness
Indoor
Blower
