SPECIFICATIONS — 559F180-300
UNIT SIZE 180 216 240 300
208/230,460 V 575 V
NOMINAL CAPACITY (tons) 15 18 20 25
OPERATING WEIGHT (lb)
Unit
Al/Al* 1500 2050 2100 2150
Economizer 110 110 110 110
Roof Curb† 200 200 200 200
COMPRESSOR Semi-Hermetic
Quantity
No. Cylinders (per circuit)
1
6
2
6
2
6
2
6
Oil (oz) 115 115,88 115 ea 128 ea
REFRIGERANT TYPE R-22
Operating Charge (lb-oz)
Circuit 1†† 19-4 13-4 12-13 16-12
Circuit 2 — 11-0 12-13 15-12
CONDENSER COIL Enhanced Copper Tubes, Aluminum Lanced Fins
Rows...Fins/in. 2...17 3...15 3...15 4...15
Total Face Area (sq ft) 22.2 22.2 22.2 22.2
CONDENSER FAN Propeller Type
Nominal Cfm 10,500 14,200 14,200
Quantity...Diameter (in.) 3...22 2...30 2...30
Motor Hp...Rpm
1
⁄
2
...1050 1...1075 1...1075
Watts Input (Total) 1100 3400 3400
EVAPORATOR COIL Copper Tubes, Aluminum or Copper Plate Fins
Expansion Device TXV Acutrol™ Feed Device
Rows...Fins/in. 2...17 3...17 3...15 4...15
Total Face Area (sq ft) 17.9 17.9 17.9 17.9
EVAPORATOR FAN Centrifugal Type
Quantity...Size (in.) 2...10 x 10 2...10 x 10 2...12 x 12 2...12 x 12 2...12 x 12
Type Drive Belt Belt Belt Belt Belt
Nominal Cfm 6000 6000 7200 8000 10,000
Motor Hp 3.7 3 5 7
1
⁄
2
10
Maximum Continuous Bhp 4.25 3.45 5.90 8.7 [208/230,575 v]
9.5 [460 v]
10.26 [208/230,575 v]
11.80 [460 v]
Motor Frame Size 56H 56H 184T 213T 215T
Fan Rpm Range 1227-1559 1201-1462 1047-1251 1238-1494 1323-1579
Motor Bearing Type Ball Ball Ball Ball Ball
Maximum Allowable Rpm 1559 1550 1550 1550 1550
Motor Pulley Pitch Diameter Min/Max (in.) 3.7/4.7 4.3/5.3 4.9/5.9 5.4/6.4 5.8/7.0
Nominal Motor Shaft Diameter (in.)
7
⁄
8
7
⁄
8
1
1
⁄
8
1
3
⁄
8
1
3
⁄
8
Fan Pulley Pitch Diameter (in.) 5.2 6.4 8.4 7.9 7.9
Belt, Quantity...Type...Length (in.) 1...BX...42 1...BX...45 1...BX..50 1...BX..50 1...BX...51
Pulley Center Line Distance (in.) — — 13.3-14.8 14.6-15.4 14.6-15.4
Speed Change per Full Turn of 66 52 34 43 43
Movable Pulley Flange (rpm)
Movable Pulley Maximum Full Turns 556 6 6
From Closed Position
Factory Setting 4 3.5 3 3 3
Factory Speed Setting (rpm) 1293 1279 1149 1366 1451
Fan Shaft Diameter at Pulley (in.) 1
3
⁄
16
1
3
⁄
16
1
7
⁄
16
1
7
⁄
16
1
7
⁄
16
HIGH-PRESSURE SWITCH (psig)
Standard Compressor Internal Relief —
Cutout 426
Reset (Auto.) 320
LOW-PRESSURE SWITCH (psig)
Cutout 7
Reset (Auto.) 22
FREEZE PROTECTION THERMOSTAT (F)
Opens 30±5
Closes 45±5
OUTDOOR-AIR INLET SCREENS Cleanable
Quantity...Size (in.) 2...20 x 25 x 1
1...20 x 20 x 1
RETURN-AIR FILTERS Throwaway\
Quantity...Size (in.) 4...20 x 20 x 2
4...16 x 20 x 2
LEGEND
Al — Aluminum
Bhp — Brake Horsepower
FIOP — Factory-Installed Option
TXV — Thermostatic Expansion Valve
*Evaporator coil fins/condenser coil fins.
†Weight of 14-in. roof curb.
**Requires the accessory controls upgrade kit.
††Circuit 1 consists of lower portion of both the condenser and evaporator coils, and
Circuit 2 consists of the upper portion of both coils.
\The 559F300 units require 2-in. industrial-grade filters capable of handling face ve-
locities up to 625 ft/min (such as American Air Filter no. 5700 or equivalent).
NOTE: The 036-150 units have a loss-of-charge/low-pressure switch (accessory or op-
tion) located in the liquid line. The 180-300 units have a low-pressure switch (standard)
located on the suction side.
