—17—
Fig. 15 — 566D150 Charging Chart
50
LIQUID PRESSURE AT LIQUID VALVE (PSIG)
LIQUID TEMPERATURE AT LIQUID VALVE (F)
344
LIQUID PRESSURE AT LIQUID VALVE (Kilopascals)
ADD CHARGE IF ABOVE CURVE
REDUCE CHARGE IF BELOW CURVE
50
60
70
80
90
100
110
120
130
140
100
150 200 250 300 350 400
689
1034
1379
1724
2069
2414
LIQUID TEMPERATURE AT LIQUID VALVE (C)
10
16
21
27
32
38
43
49
54
60
Fig. 14 — 569D072-120, 569F120, 576C090-120 Charging Chart
