Bryant 593C User Manual

—19—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
593C036-C, D Outdoor Section With CC5A/CD5AA036 Indoor Section Continued
1050
72 39.6 19.6 3.42 37.4 18.8 3.65 35.2 18.0 3.88 32.9 17.2 4.08 30.5 16.4 4.28
67 36.0 24.9 3.32 34.0 24.0 3.54 31.9 23.2 3.75 29.8 22.3 3.94 27.7 21.5 4.12
62 32.7 29.8 3.23 30.7 28.9 3.43 28.8 27.8 3.62 27.0 26.7 3.79 25.3 25.3 3.98
57 31.3 31.3 3.19 29.8 29.8 3.39 28.3 28.3 3.59 26.8 26.8 3.79 25.3 25.3 3.98
1200
72 40.3 20.5 3.49 38.1 19.7 3.73 35.8 18.9 3.96 33.3 18.1 4.17 31.0 17.3 4.38
67 36.7 26.4 3.40 34.6 25.5 3.62 32.4 24.7 3.83 30.3 23.9 4.03 28.1 23.0 4.21
62 33.4 31.8 3.31 31.4 30.7 3.51 29.5 29.4 3.71 27.8 27.8 3.90 26.2 26.2 4.10
57 32.6 32.6 3.29 31.1 31.1 3.50 29.5 29.5 3.71 27.8 27.8 3.90 26.2 26.2 4.10
1350
72 40.8 21.4 3.56 38.5 20.6 3.80 36.1 19.7 4.03 33.6 18.9 4.25 31.4 18.1 4.47
67 37.2 27.9 3.47 35.0 27.0 3.69 32.8 26.1 3.91 30.6 25.3 4.11 28.3 24.3 4.29
62 34.0 33.5 3.38 32.1 32.1 3.59 30.4 30.4 3.80 28.6 28.6 4.00 26.9 26.9 4.20
57 33.7 33.7 3.38 32.1 32.1 3.59 30.4 30.4 3.80 28.6 28.6 4.00 26.9 26.9 4.21
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity Power Capacity Power
COILS + 355MAV042060 VARIABLE-SPEED FURNACE CK5A/CK5BA 042 0.98 0.94
CC5A/CD5AA 036 1.00 0.92 CK5A/CK5BW 036 0.98 0.94
CK3BA 036 0.98 0.94
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
042 0.98 0.94 CC5A/CD5AA 036 1.00 0.92
CK5A/CK5BA 036 0.98 0.94 CK3BA 036 0.98 0.92
CK5A/CK5BN 042 0.95 0.94 042 0.98 0.92
COILS + 355MAV042080 VARIABLE-SPEED FURNACE CK5A/CK5BA 042 0.98 0.92
CC5A/CD5AA 036 1.00 0.92 CK5A/CK5BW 036 0.98 0.92
CK3BA 036 0.98 0.93
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
042 0.98 0.93 CK3BA 036 0.98 0.93
CK5A/CK5BA 042 0.98 0.93 042 0.98 0.92
CK5A/CK5BW 036 0.98 0.93 CK5A/CK5BA 042 0.98 0.92
COILS + 355MAV060080 VARIABLE-SPEED FURNACE CK5A/CK5BW 036 0.98 0.93
CK3BA 036 0.98 0.94 —— —
042 0.98 0.94
