Bryant 619E Installation, Start-Up And Service Instructions

Table 4E — Physical Data — 619E Heat Pump High Wall Fan Coil Units
UNIT 619E, HEAT PUMP 018 024
NOMINAL CAPACITY (Tons) 1
1
⁄ 2 2
NOMINAL SIZE (Btuh) 18,000 24,000
OPERATING WEIGHT (lb) 38.5 42.9
MOISTURE REMOVAL RATE (Pints/Hr) 5.6 6.3
REFRIGERANT R-22
Control (Cooling) AccuRaterT Piston in Fan Coil
Control (Heating) AccuRater Piston in Outdoor Unit
Charge Required (lb) 4.95 5.1
INDOOR FAN Direct Drive Centrifugal
Rpm/Cfm High 1120/530 1470/570
Rpm/Cfm Medium 1050/490 1370/466
Rpm/Cfm Low 950/430 1270/447
Motor Watts 42.3 49
Blowers Quantity...Size (in.) 2...3.94 x 17.8 2...3.94 x 17.8
INDOOR COIL Copper Tube, Aluminum Fin
Face Area (sq ft) 2.56 2.56
No. of Rows 23
Fins/in. 15.9 18.1
Circuits 23
FILTERS Cleanable
Quantity...Size (in.) 2...11
1
⁄ 2 x17
3
⁄ 4
AIRSWEEP
Horizontal Manual
Vertical Automatic
CONTROLS Integrated Microprocessor
Remote Controller Options Wireless
Diagnostics Yes
Defrost Method Demand Defrost
Timer Mode Yes
Warm Start Feature Yes
Test Mode Yes
Freeze Protection Yes
Dehumidification Yes
Auto. Changeover Yes
Fan Mode High/Medium/Low/Auto.
Auto Restart Yes
Control Voltage 24 v (provided)
REFRIGERANT LINES
Connection Type Flare
Liquid Line OD (in.)
3
⁄ 8
Vapor Line OD (in.)
5
⁄ 8
CONDENSATE DRAIN CONNECTION (in.)
5
⁄ 8 OD,
7
⁄ 16 ID
*Outdoor unit is shipped with a holding charge. The amount of the charge is determined based on 25 ft of line.
Table 5 — Required Piston Sizes for AccuRater Metering Device
OUTDOOR
UNIT
INDOOR
UNIT
INDOOR
PISTON
INDOOR
PISTON TYPE
OUTDOOR
PISTON
OUTDOOR
PISTON TYPE
REQUIRED SYSTEM
CHARGE (lb)*
538ANX018 619ENX018OEO 49 B N/A N/A 4.6
538ANX024 619ENX024OEO 57 B N/A N/A 5.3
538DNX018 619ENX018OHO 51 B 47 B 5.0
538DNX024 619ENX024OHO 59 B 52 B 5.1
LEGEND
N/A — Not Applicable
TXV — Thermostatic Expansion Valve
*Charge amount determined based on 25 ft of line. Check charge for longer lines using superheat method. See 538A and 538D installation, start-up,
and service instructions for system charging procedures.
NOTE: The 538S systems do not use the AccuRater device. The 538S systems have a TXV in the condensing unit for refrigerant metering and control.
—9—
