Over voltage or too low voltage protection diagnosis and solution (P1)
Error Code P1
Malfunction decision conditions
An abnormal voltage rise or drop is detected by checking the specified voltage detection
circuit.
Supposed causes
S Power supply problems
S System leakage or block
S PCB faulty
Check the power supply
Check the connections and
wires
Stop the unit
No
Yes
No
Correct the connections or
replace the wires.
Yes
Replace the reactor
Yes
No Replace the IPM board
Check the voltage between P
and N
Check the reactor
Yes
No
Replace outdoor main PCB
Fig. 37 – Troubleshooting
Remark:
Measure the DC voltage
between P and N port.
The normal value should
be around 310V.
Fig. 38 – Measure the DC voltage
To Next Page
