Bryant 698B - Page 21

—21—
DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX036-B Outdoor Section With FV4BNF006 Indoor Section - High Speed continued
900
72 43.67 21.89 2.45 40.76 20.71 2.72 37.92 19.58 2.98 35.04 18.46 3.24 32.21 17.39 3.49 29.47 16.36 3.75
67 39.13 26.10 2.43 36.49 24.92 2.68 33.81 23.74 2.93 31.16 22.61 3.17 28.56 21.51 3.41 26.02 20.46 3.65
63†† 35.92 25.10 2.42 33.38 23.89 2.65 30.88 22.72 2.88 28.42 21.59 3.11 26.02 20.51 3.34 23.58 19.44 3.56
62 35.04 30.32 2.41 32.60 29.12 2.64 30.14 27.93 2.87 27.74 26.77 3.10 25.50 25.50 3.32 23.64 23.64 3.57
57 32.86 32.86 2.39 30.99 30.99 2.62 29.18 29.18 2.85 27.33 27.33 3.09 25.50 25.50 3.32 23.64 23.64 3.57
1050
72 45.39 23.29 2.49 42.22 22.04 2.75 39.14 20.85 3.02 36.11 19.71 3.28 33.17 18.61 3.54 30.27 17.55 3.79
67 40.65 28.19 2.46 37.76 26.94 2.72 34.92 25.72 2.96 32.12 24.55 3.22 29.41 23.44 3.45 26.69 22.33 3.69
63†† 37.25 27.04 2.45 34.55 25.78 2.69 31.91 24.58 2.92 29.33 23.44 3.16 26.74 22.29 3.38 24.20 21.19 3.61
62 36.42 33.12 2.44 33.76 31.83 2.68 31.20 30.57 2.91 28.97 28.97 3.15 27.00 26.86 3.39 24.95 24.95 3.64
57 34.95 34.95 2.43 32.95 32.95 2.67 30.93 30.93 2.90 28.96 28.96 3.15 26.95 26.95 3.39 24.95 24.95 3.64
1200
72 46.60 24.53 2.51 43.30 23.26 2.78 40.08 22.05 3.05 36.95 20.89 3.32 33.88 19.77 3.58 30.85 18.69 3.83
67 41.77 30.13 2.49 38.74 28.85 2.75 35.77 27.61 3.00 32.89 26.43 3.26 30.02 25.26 3.49 27.21 24.13 3.73
63†† 38.30 28.87 2.47 35.47 27.59 2.72 32.73 26.37 2.96 29.98 25.17 3.20 27.30 24.00 3.42 24.68 22.86 3.65
62 37.47 35.73 2.47 34.75 34.35 2.71 32.50 32.50 2.96 30.31 30.31 3.20 28.18 28.18 3.45 26.08 26.08 3.70
57 36.76 36.76 2.47 34.58 34.58 2.71 32.46 32.46 2.95 30.31 30.31 3.20 28.18 28.18 3.45 26.10 26.10 3.70
1350
72 47.56 25.69 2.53 44.15 24.42 2.81 40.85 23.19 3.08 37.61 22.02 3.36 34.39 20.87 3.61 31.30 19.78 3.87
67 42.65 31.99 2.52 39.51 30.69 2.78 36.47 29.44 3.03 33.46 28.22 3.29 30.49 27.02 3.53 27.63 25.86 3.77
63†† 39.12 30.63 2.50 36.23 29.33 2.75 33.33 28.07 2.99 30.50 26.83 3.23 27.75 25.63 3.46 25.09 24.44 3.69
62 38.41 38.14 2.50 36.04 36.04 2.75 33.74 33.74 3.00 31.47 31.47 3.25 29.26 29.26 3.50 27.01 27.01 3.75
57 38.29 38.29 2.50 36.03 36.03 2.75 33.74 33.74 3.00 31.47 31.47 3.25 29.26 29.26 3.50 27.01 27.01 3.76
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CE3AA 036 0.94 0.96
CC5A/CD5AA 036 0.95 0.95 042 0.95 0.95
042 0.95 0.94 048 0.96 0.95
CC5A/CD5AC 048 0.94 0.94 CK3BA 036 0.95 0.96
CC5A/CD5AW 036 0.95 0.94 042 0.95 0.95
042 0.95 0.94 048 0.96 0.94
048 0.95 0.94 CK5A/CK5BA 042 0.95 0.95
CD5AA 048 0.95 0.94 048 0.96 0.94
CE3AA 036 0.94 0.95 CK5A/CK5BT 042 0.95 0.95
042 0.95 0.94 048 0.96 0.94
048 0.96 0.95 CK5A/CK5BW 036 0.95 0.95
CK3BA 036 0.95 0.95 048 0.97 0.94
042 0.95 0.95 CK5PA 042 0.95 0.95
048 0.96 0.94 048 0.96 0.94
CK5A/CK5BA 036 0.95 0.95 CK5PT 042 0.95 0.95
042 0.95 0.95 048 0.96 0.94
048 0.96 0.94 CK5PW 036 0.95 0.95
CK5A/CK5BE 042 0.96 0.95 048 0.97 0.94
CK5A/CK5BT 036 0.95 0.95
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
042 0.95 0.95 CC5A/CD5AA 042 0.95 0.94
048 0.96 0.94 CC5A/CD5AC 048 0.94 0.94
CK5A/CK5BW 036 0.95 0.95 CC5A/CD5AW 036 0.95 0.94
048 0.96 0.94 042 0.95 0.94
CK5PA 036 0.95 0.95 048 0.95 0.94
042 0.95 0.95 CD5AA 048 0.95 0.94
048 0.96 0.94 CE3AA 036 0.94 0.95
CK5PE 042 0.96 0.95 042 0.97 0.96
CK5PT 036 0.95 0.95 048 0.96 0.94
042 0.95 0.95 CK3BA 036 0.95 0.95
048 0.96 0.94 042 0.95 0.95
CK5PW 036 0.95 0.95 048 0.97 0.94
048 0.96 0.94 CK5A/CK5BA 042 0.95 0.94
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE 048 0.97 0.94
CC5A/CD5AA 042 0.95 0.95 CK5A/CK5BT 042 0.95 0.94
CC5A/CD5AC 048 0.94 0.95 048 0.97 0.94
CC5A/CD5AW 036 0.95 0.95 CK5A/CK5BW 036 0.95 0.94
042 0.95 0.94 048 0.97 0.94
048 0.95 0.94 CK5PA 042 0.95 0.94
CD5AA 048 0.95 0.95 048 0.97 0.94
