A-WTD. SOUND POWER (dBA)
*Sound levels are equivalent at high and low speeds.
RECOMMENDED TUBE DIAMETERS
NOTE: Maximum long-line tube length of 50 ft liquid and vapor line sets indicated
above must be followed on all applications. Over 50 ft horizontal or 20 ft vertical
differential, refer to Application Guideline and Service Manual—Air Conditioners
and Heat Pumps Using Puron® Refrigerant.
UNIT
SIZE
STANDARD
RATING*
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1,000 2,000 4,000 8,000
High Speed
024 74 52.9 58.4 58.8 68.5 57.7 53.0 45.4
036 74 53.9 59.4 60.8 65.5 58.7 53.5 48.4
048 75 53.9 59.9 59.8 63.0 60.7 53.5 48.9
060 76 54.9 63.4 59.8 67.0 60.7 57.0 49.9
UNIT
SIZE
TUBE LENGTH
(Ft)
LIQUID TUBE
DIAMETER (In.OD)
VAPOR TUBE
DIAMETER (In.OD)
024
0 to 50 3/8
5/8
036 3/4
048 7/8
060 1-1/8
