—42—
HEAT PUMP HEATING PERFORMANCE continued
See notes on page 56.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡
698BNX036-B Outdoor Section With FV4BNB006 Indoor Section - High Speed
65
900 9.97 9.17 1.65 13.59 12.49 1.82 17.52 15.98 1.98 21.98 19.52 2.15 26.90 24.48 2.33 32.34 32.34 2.52 38.82 38.82 2.77 46.27 46.27 3.02
1050 10.27 9.45 1.67 13.93 12.80 1.83 17.97 16.38 1.99 22.56 20.04 2.15 27.62 25.14 2.31 33.24 33.24 2.50 39.99 39.99 2.70 44.18 44.18 2.83
1200 10.48 9.64 1.69 14.20 13.05 1.84 18.31 16.69 1.99 23.00 20.43 2.15 28.11 25.58 2.30 33.71 33.71 2.50 38.28 38.28 2.60 39.51 39.51 2.63
1350 10.68 9.82 1.70 14.44 13.27 1.86 18.66 17.01 2.01 23.33 20.72 2.15 28.44 25.88 2.31 34.14 34.14 2.46 35.57 35.57 2.50 36.38 36.38 2.52
70
900 9.24 8.50 1.66 12.88 11.83 1.85 16.81 15.33 2.02 21.18 18.81 2.20 26.26 24.29 2.40 31.38 31.38 2.59 37.66 37.66 2.84 44.90 44.90 3.14
1050 9.49 8.73 1.68 13.22 12.15 1.86 17.23 15.71 2.03 21.73 19.30 2.20 26.69 24.29 2.37 32.23 32.23 2.56 38.66 38.66 2.81 45.17 45.17 2.99
1200 9.70 8.93 1.70 13.51 12.42 1.88 17.58 16.03 2.04 22.13 19.66 2.20 27.20 24.75 2.36 32.74 32.74 2.55 38.96 38.96 2.73 40.64 40.64 2.78
1350 9.90 9.10 1.72 13.73 12.62 1.89 17.86 16.28 2.05 22.52 20.00 2.20 27.60 25.12 2.37 33.22 33.22 2.56 36.53 36.53 2.64 37.18 37.18 2.65
75
900 8.48 7.80 1.67 12.14 11.15 1.88 16.08 14.66 2.06 20.36 18.08 2.25 25.18 22.91 2.45 30.43 30.43 2.66 36.51 36.51 2.91 43.67 43.67 3.22
1050 8.70 8.00 1.69 12.48 11.47 1.89 16.49 15.03 2.07 20.92 18.58 2.25 25.80 23.48 2.43 31.25 31.25 2.63 37.52 37.52 2.87 44.58 44.58 3.09
1200 8.91 8.19 1.71 12.75 11.72 1.90 16.80 15.32 2.07 21.34 18.96 2.25 26.30 23.93 2.42 31.81 31.81 2.62 38.36 38.36 2.82 41.68 41.68 2.93
1350 9.10 8.37 1.73 12.98 11.93 1.92 17.10 15.59 2.09 21.67 19.25 2.26 26.69 24.29 2.43 32.16 32.16 2.63 37.40 37.40 2.77 38.40 38.40 2.80
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 036 1.01 1.09
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE
042 1.01 1.09 CC5A/CD5AA 036 0.96 1.06
CC5A/CD5AC 048 0.99 1.11 CE3AA 036 0.96 1.07
CC5A/CD5AW 036 1.01 1.09 CK3BA 036 0.97 1.05
042 1.01 1.10 CK5A/CK5BA 036 0.97 1.05
048 1.02 1.07 CK5A/CK5BT 036 0.97 1.05
CD5AA 048 1.03 1.09 CK5PA 036 0.97 1.05
CE3AA 036 1.00 1.10 CK5PT 036 0.97 1.05
042 1.02 1.09
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE
048 1.02 1.09 CC5A/CD5AA 036 0.96 1.05
CF5AA 036 1.01 1.10 042 0.96 1.04
048 1.01 1.10 CC5A/CD5AC 048 0.94 1.05
CK3BA 036 1.01 1.09 CC5A/CD5AW 036 0.96 1.04
042 1.01 1.09 CD5AA 048 0.95 1.01
048 1.02 1.09 CE3AA 036 0.95 1.05
CK5A/CK5BA 036 1.02 1.09 042 0.96 1.03
042 1.02 1.09 048 0.97 1.03
048 1.02 1.08 CK3BA 036 0.97 1.04
CK5A/CK5BE 042 1.02 1.08 042 0.97 1.04
CK5A/CK5BT 036 1.02 1.09 048 0.98 1.03
042 1.02 1.09 CK5A/CK5BA 036 0.97 1.04
048 1.02 1.08 042 0.97 1.04
CK5A/CK5BW 036 1.02 1.09 048 0.98 1.03
048 1.02 1.08 CK5A/CK5BE 042 0.98 1.04
CK5PA 036 1.02 1.09 CK5A/CK5BT 036 0.97 1.04
042 1.02 1.09 042 0.97 1.04
048 1.02 1.08 048 0.98 1.03
CK5PBE 042 1.02 1.08 CK5A/CK5BW 036 0.97 1.04
CK5PT 036 1.02 1.09 CK5PA 036 0.97 1.04
042 1.02 1.09 042 0.97 1.04
048 1.02 1.08 048 0.98 1.03
CK5PW 036 1.02 1.09 CK5PE 042 0.98 1.04
048 1.02 1.08 CK5PT 036 0.97 1.04
FE4ANB 006 1.00 1.00 042 0.97 1.04
FE4ANF 002 1.00 1.06 048 0.98 1.03
003 1.00 1.05 CK5PW 036 0.97 1.04
005 1.00 1.03
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE
FK4DNF 001 1.00 1.11 CC5A/CD5AA 036 0.96 1.04
FV4BNB 006 1.00 1.00 042 0.96 1.03
FV4BNF 002 1.00 1.06 CC5A/CD5AC 048 0.94 1.04
003 1.00 1.05 CC5A/CD5AW 036 0.96 1.03
005 1.00 1.03 042 0.95 1.01
40FKB/FK4DNB 006 1.00 1.00 048 0.95 1.00
40FKB/FK4DNF 002 1.00 1.06 CD5AA 048 0.96 1.02
003 1.00 1.05 CE3AA 036 0.94 1.04
005 1.00 1.03 042 0.96 1.03
—— — 048 0.97 1.02
