—47—
HEAT PUMP HEATING PERFORMANCE continued
See notes on page 56.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
17 27 37 47 57 67
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡
698BNX036-B Outdoor Section With FV4BNB006 Indoor Section - Low Speed continued
65
650 7.29 6.65 0.99 9.89 8.78 1.05 12.65 11.52 1.10 15.65 15.65 1.16 18.84 18.84 1.21 22.26 22.26 1.27
825 7.64 6.96 1.00 10.34 9.19 1.05 13.21 12.02 1.10 16.35 16.35 1.15 19.66 19.66 1.19 23.36 23.36 1.24
1000 7.89 7.19 1.01 10.65 9.46 1.06 13.60 12.38 1.10 16.81 16.81 1.14 20.23 20.23 1.18 24.06 24.06 1.22
1175 8.07 7.36 1.01 10.88 9.66 1.06 13.88 12.63 1.10 17.18 17.18 1.14 20.62 20.62 1.18 24.45 24.45 1.22
1350 8.21 7.49 1.02 11.05 9.81 1.07 14.09 12.82 1.11 17.36 17.36 1.14 20.89 20.89 1.18 24.79 24.79 1.20
70
650 6.61 6.03 1.00 9.21 8.18 1.07 11.96 10.88 1.12 14.96 14.96 1.19 18.15 18.15 1.25 21.50 21.50 1.31
825 6.94 6.33 1.01 9.64 8.56 1.07 12.52 11.39 1.12 15.65 15.65 1.17 18.92 18.92 1.22 22.55 22.55 1.27
1000 7.15 6.52 1.02 9.97 8.85 1.07 12.91 11.75 1.12 16.14 16.14 1.17 19.49 19.49 1.21 23.27 23.27 1.26
1175 7.35 6.70 1.03 10.19 9.05 1.08 13.16 11.97 1.12 16.40 16.40 1.16 19.90 19.90 1.21 23.72 23.72 1.25
1350 7.48 6.82 1.04 10.36 9.20 1.09 13.40 12.19 1.13 16.70 16.70 1.17 20.16 20.16 1.21 24.14 24.14 1.24
75
650 5.90 5.38 1.01 8.51 7.56 1.08 11.25 10.23 1.14 14.23 14.23 1.21 17.45 17.45 1.27 20.79 20.79 1.34
825 6.22 5.67 1.02 8.94 7.94 1.08 11.80 10.74 1.14 14.93 14.93 1.20 18.23 18.23 1.25 21.76 21.76 1.31
1000 6.44 5.87 1.03 9.24 8.21 1.09 12.18 11.08 1.14 15.39 15.39 1.20 18.78 18.78 1.24 22.43 22.43 1.29
1175 6.59 6.01 1.04 9.47 8.41 1.10 12.46 11.33 1.15 15.72 15.72 1.20 19.18 19.18 1.24 22.93 22.93 1.28
1350 6.73 6.14 1.05 9.63 8.55 1.10 12.66 11.52 1.16 15.98 15.98 1.20 19.47 19.47 1.24 23.30 23.30 1.28
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CE3AA 036 0.99 1.05
CC5A/CD5AA 036 0.99 1.04 042 1.00 1.04
042 1.01 1.08 048 1.00 1.04
CC5A/CD5AC 048 0.97 1.04 CK3BA 036 1.00 1.04
CC5A/CD5AW 036 1.01 1.08 042 1.00 1.04
042 0.99 1.03 048 1.00 1.03
048 0.99 1.03 CK5A/CK5BA 042 1.00 1.04
CD5AA 048 0.99 1.03 048 1.00 1.03
CE3AA 036 1.00 1.08 CK5A/CK5BT 042 1.00 1.04
042 1.00 1.04 048 1.00 1.03
048 1.01 1.06 CK5A/CK5BW 036 1.00 1.04
CK3BA 036 1.00 1.04 048 1.00 1.03
042 1.00 1.04 CK5PA 042 1.00 1.04
048 1.00 1.03 048 1.00 1.03
CK5A/CK5BA 036 1.00 1.04 CK5PT 042 1.00 1.04
042 1.00 1.04 048 1.00 1.03
048 1.00 1.03 CK5PW 036 1.00 1.04
CK5A/CK5BE 042 1.00 1.03 048 1.00 1.03
CK5A/CK5BT 036 1.00 1.04
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
042 1.00 1.04 CC5A/CD5AA 042 0.99 1.04
048 1.00 1.03 CC5A/CD5AC 048 0.97 1.04
CK5A/CK5BW 036 1.00 1.04 CC5A/CD5AW 036 0.99 1.04
048 1.00 1.03 042 0.99 1.03
CK5PA 036 1.00 1.04 048 0.99 1.03
042 1.00 1.04 CD5AA 048 0.99 1.03
048 1.00 1.03 CE3AA 036 0.99 1.05
CK5PE 042 1.00 1.03 042 1.00 1.04
CK5PT 036 1.00 1.04 048 1.00 1.04
042 1.00 1.04 CK3BA 036 1.00 1.04
048 1.00 1.03 042 1.00 1.04
CK5PW 036 1.00 1.04 048 1.00 1.03
048 1.00 1.03 CK5A/CK5BA 042 1.00 1.03
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE 048 1.00 1.03
CC5A/CD5AA 042 0.99 1.04 CK5A/CK5BT 042 1.00 1.03
CC5A/CD5AC 048 0.99 1.06 048 1.00 1.03
CC5A/CD5AW 036 0.99 1.04 CK5A/CK5BW 036 1.00 1.03
042 0.99 1.03 048 1.00 1.03
048 0.99 1.03 CK5PA 042 1.00 1.03
CD5AA 048 0.99 1.03 048 1.00 1.03
