Bryant 698B - Page 51

—51—
HEAT PUMP HEATING PERFORMANCE continued
See notes on page 56.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 2737475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡
698BNX048-B Outdoor Section With FV4BNF005 Indoor Section - High Speed
65
1200 19.71 18.13 2.70 25.38 23.32 2.95 31.54 28.76 3.25 38.19 33.92 3.57 43.43 39.52 3.77 44.38 44.38 3.79 45.62 45.62 3.84 45.89 45.89 3.83
1400 20.21 18.59 2.75 25.90 23.80 3.00 32.02 29.20 3.30 39.02 34.65 3.58 41.36 37.64 3.68 41.88 41.88 3.69 42.39 42.39 3.70 43.22 43.22 3.72
1600 20.60 18.95 2.80 26.35 24.22 3.06 32.38 29.53 3.35 38.20 33.93 3.57 39.31 35.77 3.61 39.79 39.79 3.62 40.37 40.37 3.64 41.11 41.11 3.65
1800 21.01 19.33 2.85 26.79 24.62 3.12 32.75 29.86 3.41 37.34 33.17 3.57 38.24 34.80 3.60 38.45 38.45 3.60 38.91 38.91 3.61 39.58 39.58 3.61
70
1200 18.76 17.26 2.72 24.79 22.78 3.03 30.53 27.83 3.29 37.06 32.91 3.62 44.28 40.30 3.93 45.48 45.48 3.96 46.55 46.55 3.99 47.55 47.55 4.02
1400 19.25 17.71 2.78 24.97 22.95 3.04 31.13 28.38 3.34 37.80 33.57 3.65 41.98 38.21 3.82 43.35 43.35 3.87 44.01 44.01 3.89 44.61 44.61 3.89
1600 19.65 18.08 2.83 25.44 23.38 3.09 31.55 28.76 3.40 38.39 34.10 3.68 40.10 36.49 3.75 40.93 40.93 3.78 41.80 41.80 3.81 42.44 42.44 3.81
1800 20.02 18.42 2.88 25.82 23.72 3.14 31.87 29.05 3.45 37.94 33.70 3.70 39.15 35.63 3.74 39.70 39.70 3.75 40.39 40.39 3.78 40.96 40.96 3.78
75
1200 17.83 16.40 2.75 23.39 21.50 3.02 29.49 26.89 3.32 36.03 32.00 3.67 43.65 39.72 4.01 46.26 46.26 4.12 47.49 47.49 4.17 49.18 49.18 4.23
1400 18.31 16.85 2.80 23.97 22.02 3.07 30.11 27.45 3.38 36.58 32.49 3.72 42.96 39.09 3.98 43.84 43.84 4.00 44.84 44.84 4.04 45.67 45.67 4.05
1600 18.73 17.23 2.86 24.43 22.45 3.12 30.62 27.92 3.44 37.23 33.07 3.75 41.05 37.36 3.91 42.13 42.13 3.94 42.83 42.83 3.97 43.57 43.57 3.97
1800 19.10 17.57 2.91 24.83 22.82 3.17 30.99 28.26 3.49 37.84 33.61 3.79 39.80 36.22 3.88 40.60 40.60 3.90 41.50 41.50 3.93 41.89 41.89 3.93
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.98 1.04 CK5A/CK5BA 048 1.00 1.14
CC5A/CD5AC 048 0.96 1.05 060 1.01 1.12
CC5A/CD5AW 048 1.00 1.04 CK5A/CK5BT 048 1.00 1.13
060 1.01 1.04 060 1.01 1.12
CD5AA 048 1.00 1.04 CK5A/CK5BW 048 1.00 1.13
CE3AA 048 0.98 1.02 CK5A/CK5BX 060 0.99 1.09
060 0.99 1.04 CK5PA 048 1.00 1.14
CK3BA 048 1.00 1.04 060 1.01 1.12
060 1.01 1.03 CK5PT 048 1.00 1.13
CK5A/CK5BA 048 1.00 1.04 060 1.01 1.12
060 1.01 1.03 CK5PW 048 1.00 1.13
CK5A/CK5BT 048 1.00 1.04 CK5PX 060 0.99 1.09
060 1.01 1.03
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE
CK5A/CK5BW 048 1.00 1.04 CC5A/CD5AA 060 0.99 1.15
CK5A/CK5BX 060 1.00 1.04 CC5A/CD5AC 048 0.98 1.16
CK5PA 048 1.00 1.04 CC5A/CD5AW 048 1.00 1.14
060 1.01 1.03 060 1.00 1.08
CK5PT 048 1.00 1.04 CD5AA 048 1.00 1.14
060 1.01 1.03 CE3AA 048 1.00 1.14
CK5PW 048 1.00 1.04 060 1.00 1.13
CK5PX 060 1.00 1.04 CK3BA 048 1.00 1.14
FE4ANB 006 1.01 0.97 060 1.01 1.13
FE4ANF 005 1.00 1.00 CK5A/CK5BA 048 1.00 1.13
FV4BNB 006 1.01 0.97 060 1.01 1.13
FV4BNF 005 1.00 1.00 CK5A/CK5BT 048 1.00 1.14
40FKB/FK4DNB 006 1.01 0.97 060 1.00 1.11
40FKB/FK4DNF 005 1.00 1.00 CK5A/CK5BW 048 1.00 1.13
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE CK5A/CK5BX 060 0.99 1.09
CC5A/CD5AC 048 1.00 1.01 CK5PA 048 1.00 1.13
CD5AA 048 1.00 1.01 060 1.01 1.13
CE3AA 048 1.00 1.15 CK5PT 048 1.00 1.14
CK3BA 048 1.00 1.15 060 1.00 1.11
CK5A/CK5BA 048 1.00 1.15 CK5PW 048 1.00 1.13
CK5A/CK5BT 048 1.00 1.15 CK5PX 060 0.99 1.09
CK5PA 048 1.00 1.15
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
CK5PT 048 1.00 1.15 CC5A/CD5AA 060 0.99 1.14
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CC5A/CD5AC 048 0.96 1.14
CC5A/CD5AA 060 0.99 1.14 CC5A/CD5AW 048 0.99 1.12
CC5A/CD5AC 048 0.98 1.15 060 1.00 1.07
CC5A/CD5AW 048 1.00 1.14 CD5AA 048 0.99 1.12
CD5AA 048 1.00 1.14 CE3AA 048 1.00 1.14
CE3AA 048 0.99 1.12 060 1.00 1.13
060 1.00 1.13 CK3BA 048 0.99 1.11
CK3BA 048 1.00 1.13 060 1.01 1.12
060 1.01 1.12 CK5A/CK5BA 048 1.00 1.13
—— — 060 1.01 1.12
