COMBINATION RATINGS
UNIT
SIZE
SERIES
INDOOR
UNIT
Heating
HSPF
Cooling
High-Temp Low-Temp
CFM TC
SEER EER
TC Cop TC Cop
High Low
High Low
High Low High Low High Low High Low
024-B
*FV4BNF002 735 440 24,000 12,000 14.00 11.00 21,000 10,600 3.38 3.40 12,400 4,400 2.34 1.52 7.80
CC5A/CD5AA024 750 450 22,000 11,800 11.50 9.45 20,400 10,800 2.92 2.92 12,800 4,700 2.08 1.36 7.00
CC5A/CD5AA030 750 450 22,800 11,600 12.00 10.30 20,200 10,800 2.90 2.94 12,800 4,700 2.10 1.38 7.00
CC5A/CD5AA036 750 450 23,400 12,000 12.00 10.10 21,000 11,000 3.06 3.02 13,100 4,900 2.16 1.40 7.20
CC5A/CD5AW024 750 450 22,000 11,600 11.50 9.45 20,400 10,800 2.92 2.92 12,800 4,700 2.08 1.36 7.00
CC5A/CD5AW030 750 450 22,200 11,600 11.50 9.65 20,200 10,800 2.90 2.94 12,800 4,700 2.10 1.38 7.00
CC5A/CD5AW036 750 450 23,400 12,000 12.00 10.10 21,000 11,000 3.06 3.02 13,100 4,900 2.16 1.40 7.20
CE3AA024 750 450 22,200 11,600 11.50 9.45 20,600 10,800 2.96 2.96 12,900 4,800 2.12 1.38 7.10
CE3AA030 750 450 22,600 11,800 11.50 9.70 21,000 11,000 3.04 3.00 13,000 4,800 2.14 1.38 7.20
CE3AA036 750 450 23,000 11,800 12.00 9.85 20,800 10,800 2.98 3.00 13,000 4,800 2.14 1.40 7.20
CF5AA024 750 450 22,400 11,600 11.50 9.60 20,600 10,800 2.98 2.96 12,900 4,700 2.10 1.38 7.10
CF5AA036 750 450 22,800 11,800 12.00 10.00 21,000 11,000 3.02 3.02 13,000 4,900 2.16 1.40 7.20
CK3BA024 750 450 22,400 11,800 11.50 9.50 21,200 11,000 3.12 3.04 13,100 4,900 2.16 1.40 7.20
CK3BA030 750 450 22,600 11,800 11.50 9.70 20,600 11,000 2.96 3.02 13,100 4,800 2.16 1.40 7.20
CK3BA036 750 450 23,400 12,000 12.00 10.00 21,000 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5A/CK5BA024 750 450 22,400 11,800 11.50 9.50 21,200 11,000 3.12 3.04 13,100 4,900 2.16 1.40 7.20
CK5A/CK5BA030 750 450 22,600 11,800 11.50 9.70 20,600 11,000 2.96 3.02 13,100 4,800 2.16 1.40 7.20
CK5A/CK5BA036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5A/CK5BT036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5A/CK5BW024 750 450 22,400 11,800 11.50 9.50 21,200 11,000 3.12 3.04 13,100 4,900 2.16 1.40 7.20
CK5A/CK5BW030 750 450 22,600 11,800 11.50 9.70 20,600 11,000 2.96 3.02 13,100 4,800 2.16 1.40 7.20
CK5A/CK5BW036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5PA024 750 450 22,400 11,800 11.50 9.50 21,200 11,000 3.12 3.04 13,100 4,900 2.16 1.40 7.20
CK5PA030 750 450 22,600 11,800 11.50 9.70 20,600 11,000 2.96 3.02 13,100 4,800 2.16 1.40 7.20
CK5PA036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5PT036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
CK5PW024 750 450 22,400 11,800 11.50 9.50 21,200 11,000 3.12 3.04 13,100 4,900 2.16 1.40 7.20
CK5PW030 750 450 22,600 11,800 11.50 9.70 20,600 11,000 2.96 3.02 13,100 4,800 2.16 1.40 7.20
CK5PW036 750 450 23,400 12,000 12.00 10.00 21,200 10,800 3.08 3.08 13,200 4,800 2.18 1.40 7.30
FE4ANF002 735 440 24,000 12,000 14.00 11.00 21,000 10,600 3.38 3.40 12,400 4,400 2.34 1.52 7.80
FE4ANF003 735 440 24,000 12,000 14.00 11.20 20,600 10,600 3.30 3.38 12,200 4,400 2.36 1.52 7.80
FK4DNF001 735 440 23,800 12,000 14.00 10.90 20,600 10,600 3.24 3.34 12,300 4,400 2.30 1.52 7.80
FV4BNF003 735 440 24,000 12,000 14.00 11.20 20,600 10,600 3.30 3.38 12,200 4,400 2.36 1.52 7.80
40FKB/FK4DNF002 735 440 24,000 12,000 14.00 11.00 21,000 10,600 3.38 3.40 12,400 4,400 2.34 1.52 7.80
40FKB/FK4DNF003 735 440 24,000 12,000 14.00 11.20 20,600 10,600 3.30 3.38 12,200 4,400 2.36 1.52 7.80
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE
CC5A/CD5AA024 700 525 22,600 12,000 13.50 10.55 20,200 10,800 3.04 3.28 11,800 4,500 2.20 1.48 7.60
CC5A/CD5AA030 700 525 23,000 12,000 13.50 10.75 20,200 10,800 3.06 3.34 11,800 4,600 2.24 1.62 7.70
CC5A/CD5AA036 700 525 23,800 12,000 14.00 11.00 20,200 11,000 3.24 3.44 12,100 4,600 2.30 1.64 8.00
CC5A/CD5AW024 700 525 22,600 12,000 13.50 10.60 20,200 10,600 3.06 3.30 11,700 4,500 2.22 1.50 7.60
CC5A/CD5AW030 700 525 23,000 12,000 13.50 10.75 20,200 10,800 3.06 3.34 13,900 4,500 2.52 1.62 8.20
CE3AA024 700 525 22,800 12,000 13.50 10.65 20,400 10,800 3.12 3.34 11,900 4,600 2.24 1.50 7.70
CE3AA030 700 525 23,200 12,000 13.50 10.80 20,200 10,800 3.06 3.40 13,900 4,600 2.52 1.52 8.30
CE3AA036 700 525 23,400 12,000 14.00 10.90 20,200 10,800 3.06 3.42 13,900 4,600 2.52 1.54 8.30
CK3BA024 700 525 23,000 12,000 14.00 10.85 19,600 11,000 3.12 3.46 13,900 4,600 2.50 1.54 8.40
CK3BA030 700 525 23,200 12,000 14.00 10.90 19,800 11,000 3.12 3.44 13,900 4,600 2.52 1.52 8.40
CK3BA036 700 525 23,800 12,000 14.00 11.05 20,200 11,000 3.06 3.50 13,900 4,600 2.52 1.56 8.40
CK5A/CK5BA024 700 525 23,800 12,000 14.00 10.95 20,200 11,000 3.04 3.48 14,000 4,700 2.50 1.56 8.40
CK5A/CK5BA030 700 525 23,800 12,000 14.00 11.00 20,200 11,000 3.04 3.48 11,500 4,700 3.38 1.56 8.70
CK5A/CK5BA036 700 525 23,800 12,000 14.00 11.05 20,200 11,000 3.06 3.50 13,900 4,700 2.52 1.56 8.40
CK5A/CK5BT036 700 525 23,800 12,000 14.00 11.05 20,200 11,000 3.06 3.50 13,900 4,700 2.52 1.56 8.40
CK5A/CK5BW024 700 525 23,800 12,000 14.00 10.95 20,200 11,000 3.04 3.48 14,000 4,700 2.50 1.56 8.40
CK5A/CK5BW030 700 525 23,800 12,000 14.00 11.05 21,200 11,000 3.28 3.50 13,900 4,700 2.52 1.56 8.40
CK5PA024 700 525 23,800 12,000 14.00 10.95 19,800 11,000 3.22 3.48 12,300 4,600 2.32 1.52 8.00
CK5PA030 700 525 23,800 12,000 14.00 11.00 19,800 11,000 3.24 3.48 12,300 4,700 2.32 1.54 8.00
CK5PA036 700 525 23,800 12,000 14.00 11.05 19,800 11,000 3.26 3.50 12,200 4,600 2.34 1.54 8.10
CK5PT036 700 525 23,800 12,000 14.00 11.05 19,800 11,000 3.26 3.50 12,200 4,600 2.34 1.54 8.10
CK5PW024 700 525 23,800 12,000 14.00 10.95 19,800 11,000 3.24 3.48 12,300 4,700 2.32 1.54 8.00
CK5PW030 700 525 23,800 12,000 14.00 11.00 19,800 11,000 3.26 3.50 12,200 4,600 2.34 1.54 8.10
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE
CC5A/CD5AA024 700 525 22,600 12,000 13.50 10.60 20,200 11,000 3.06 3.28 13,900 4,600 2.52 1.50 8.10
CC5A/CD5AA030 700 525 23,000 12,000 13.50 10.85 20,200 11,000 3.06 3.32 13,900 4,500 2.52 1.50 8.20
CC5A/CD5AA036 700 525 23,800 12,000 14.00 11.10 20,200 11,000 3.06 3.46 13,900 4,600 2.54 1.54 8.40
CC5A/CD5AW024 700 525 22,600 12,000 13.50 10.70 20,200 10,800 3.08 3.30 13,900 4,500 2.52 1.52 8.20
CC5A/CD5AW030 700 525 23,000 12,000 13.50 10.85 20,200 10,800 3.08 3.32 13,900 4,500 2.52 1.50 8.20
CC5A/CD5AW036 700 525 23,800 12,000 14.00 11.10 20,200 11,000 3.08 3.46 13,900 4,600 2.54 1.54 8.40
CE3AA024 700 525 23,000 12,000 13.50 10.70 20,200 11,000 3.06 3.34 13,900 4,600 2.52 1.52 8.20
CE3AA030 700 525 23,200 12,000 13.50 10.90 20,200 10,800 3.08 3.42 13,900 4,600 2.52 1.54 8.30
CE3AA036 700 525 23,600 12,000 14.00 11.00 20,200 10,800 3.08 3.42 13,900 4,600 2.52 1.54 8.30
CK3BA024 700 525 23,200 12,000 14.00 10.95 20,000 11,000 3.08 3.46 13,900 4,600 2.52 1.56 8.40
CK3BA030 700 525 23,400 12,000 14.00 11.00 20,200 11,000 3.08 3.44 13,900 4,600 2.52 1.54 8.40
CK3BA036 700 525 24,000 12,000 14.00 11.15 20,200 11,000 3.08 3.52 13,900 4,600 2.52 1.56 8.50
CK5A/CK5BA024 700 525 23,800 12,000 14.00 11.00 20,200 11,000 3.04 3.48 13,900 4,700 2.50 1.56 8.40
CK5A/CK5BA030 700 525 23,800 12,000 14.00 11.05 20,200 11,000 3.06 3.48 13,900 4,700 2.52 1.56 8.40
CK5A/CK5BA036 700 525 24,000 12,000 14.00 11.15 20,200 11,000 3.08 3.52 13,900 4,600 2.52 1.56 8.50
CK5A/CK5BT036 700 525 24,000 12,000 14.00 11.15 20,200 11,000 3.08 3.52 13,900 4,600 2.52 1.56 8.50
CK5A/CK5BW024 700 525 23,800 12,000 14.00 11.05 20,200 11,000 3.06 3.48 13,900 4,700 2.50 1.56 8.40
CK5A/CK5BW030 700 525 24,000 12,000 14.00 11.10 20,200 11,000 3.06 3.52 13,900 4,600 2.52 1.56 8.50
CK5A/CK5BW036 700 525 24,000 12,000 14.00 11.15 20,200 11,000 3.08 3.52 13,900 4,600 2.54 1.56 8.50
CK5PA024 700 525 23,800 12,000 14.00 11.00 19,800 11,000 3.24 3.48 12,200 4,600 2.32 1.54 8.10
CK5PA030 700 525 23,800 12,000 14.00 11.05 19,800 11,000 3.26 3.48 12,200 4,600 2.34 1.54 8.10
CK5PA036 700 525 23,800 12,000 14.00 11.15 19,800 11,000 3.28 3.50 12,200 4,600 2.34 1.56 8.10
See notes on page 14.
