CK5A/CK5BT048 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.32 3.42 19,700 7,800 2.30 1.66 8.00
CK5A/CK5BW036 1200 850 34,200 17,200 12.50 10.30 33,200 17,000 3.26 3.40 19,600 7,800 2.28 1.66 8.00
CK5A/CK5BW048 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.34 3.72 19,100 7,300 2.32 1.78 8.00
CK5PA036 1200 720 34,200 17,000 12.50 10.30 33,200 16,400 3.26 3.40 19,600 7,800 2.28 1.66 8.00
CK5PA042 1200 720 34,200 17,000 12.50 10.30 33,200 16,400 3.26 3.40 19,600 7,800 2.28 1.66 8.00
CK5PA048 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.32 3.42 19,700 7,800 2.30 1.66 8.00
CK5PE042 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.32 3.42 19,700 7,800 2.30 1.66 8.00
CK5PT036 1200 720 34,200 17,000 12.50 10.30 33,200 16,400 3.26 3.34 19,500 7,800 2.26 1.66 8.00
CK5PT042 1200 720 34,200 17,000 12.50 10.30 33,200 16,400 3.26 3.40 19,600 7,800 2.28 1.66 8.00
CK5PT048 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.32 3.42 19,700 7,800 2.30 1.66 8.00
CK5PW036 1200 850 34,200 17,200 12.50 10.30 33,200 17,000 3.26 3.40 19,600 7,800 2.28 1.66 8.00
CK5PW048 1200 720 34,400 17,000 12.50 10.35 33,400 16,400 3.34 3.72 19,100 7,300 2.32 1.78 8.00
FE4ANB006 1100 660 35,200 17,600 16.00 11.65 32,400 15,000 3.70 3.72 18,500 6,200 2.50 1.64 8.80
FE4ANF002 1100 660 34,200 16,800 14.50 10.60 32,400 15,000 3.48 3.72 18,600 7,000 2.36 1.78 8.30
FE4ANF003 1100 660 34,600 17,000 15.00 11.15 32,400 15,000 3.52 3.78 18,600 7,000 2.42 1.80 8.50
FE4ANF005 1100 660 35,000 17,400 15.50 11.70 32,400 15,000 3.60 3.84 19,000 7,100 2.50 1.84 8.60
FK4DNF001 1100 660 33,800 16,800 14.00 10.40 32,400 15,000 3.32 3.66 18,600 6,900 2.30 1.76 8.00
FV4BNF002 1100 660 34,200 16,800 14.50 10.60 32,400 15,000 3.48 3.72 18,600 7,000 2.36 1.78 8.30
FV4BNF003 1100 660 34,600 17,000 15.00 11.15 32,400 15,000 3.52 3.78 18,600 7,000 2.42 1.80 8.50
FV4BNF005 1100 660 35,000 17,400 15.50 11.70 32,400 15,000 3.60 3.84 19,000 7,100 2.50 1.84 8.60
40FKB/FK4DNB006 1100 660 35,200 17,600 16.00 11.65 32,400 15,000 3.70 3.72 18,500 6,200 2.50 1.64 8.80
40FKB/FK4DNF002 1100 660 34,200 16,800 14.50 10.60 32,400 15,000 3.48 3.72 18,600 7,000 2.36 1.78 8.30
40FKB/FK4DNF003 1100 660 34,600 17,000 15.00 11.15 32,400 15,000 3.52 3.78 18,600 7,000 2.42 1.80 8.50
40FKB/FK4DNF005 1100 660 35,000 17,400 15.50 11.70 32,400 15,000 3.60 3.84 19,000 7,100 2.50 1.84 8.60
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,200 17,400 15.00 11.30 31,200 14,800 3.36 3.50 18,000 6,200 2.28 1.56 8.00
CE3AA036 1050 700 32,800 17,200 15.00 11.15 31,000 15,200 3.32 3.42 17,900 6,100 2.28 1.54 7.90
CK3BA036 1050 700 33,400 17,400 15.50 11.40 31,400 15,000 3.42 3.54 18,200 6,300 2.32 1.58 8.10
CK5A/CK5BA036 1050 700 33,400 17,400 15.50 11.35 31,400 15,000 3.42 3.54 18,200 6,300 2.32 1.58 8.10
CK5A/CK5BT036 1050 700 33,400 17,400 15.50 11.35 31,400 15,000 3.42 3.54 18,200 6,300 2.32 1.58 8.10
CK5PA036 1050 700 33,400 17,400 15.50 11.35 31,400 15,000 3.42 3.54 18,200 6,300 2.32 1.58 8.10
CK5PT036 1050 700 33,400 17,400 15.50 11.35 31,400 15,000 3.42 3.54 18,200 6,300 2.32 1.58 8.10
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,400 17,400 15.50 11.50 31,200 15,200 3.40 3.48 17,900 6,100 2.32 1.56 8.00
CC5A/CD5AA042 1050 700 33,400 17,400 15.50 11.60 31,000 14,800 3.42 3.52 17,800 6,100 2.32 1.56 8.10
CC5A/CD5AC048 1050 700 33,000 17,200 15.50 11.50 30,400 14,600 3.32 3.48 17,700 6,100 2.30 1.56 8.00
CC5A/CD5AW036 1050 700 33,400 17,400 15.50 11.60 31,000 14,800 3.42 3.52 17,800 6,100 2.32 1.56 8.10
CD5AA048 1050 700 33,400 17,400 15.50 11.70 30,800 15,200 3.48 3.52 18,000 6,100 2.34 1.58 8.10
CE3AA036 1050 700 33,000 17,200 15.00 11.35 30,800 15,000 3.36 3.44 17,800 6,100 2.30 1.56 8.00
CE3AA042 1050 700 33,600 17,400 15.50 11.65 31,200 15,200 3.46 3.52 17,900 6,200 2.34 1.58 8.10
CE3AA048 1050 700 33,800 17,600 15.50 11.75 31,400 15,000 3.48 3.58 17,900 6,200 2.36 1.58 8.20
CK3BA036 1050 700 33,600 17,600 15.50 11.60 31,400 15,000 3.44 3.58 18,100 6,200 2.34 1.58 8.20
CK3BA042 1050 700 33,600 17,600 15.50 11.60 31,400 15,000 3.46 3.58 18,100 6,200 2.36 1.58 8.20
CK3BA048 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.50 3.60 18,200 6,200 2.38 1.60 8.30
CK5A/CK5BA036 1050 700 33,600 17,600 15.50 11.55 31,400 15,000 3.44 3.58 18,100 6,200 2.34 1.58 8.20
CK5A/CK5BA042 1050 700 33,600 17,600 15.50 11.65 31,400 15,200 3.46 3.56 18,100 6,200 2.36 1.58 8.20
CK5A/CK5BA048 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.50 3.60 18,200 6,200 2.38 1.60 8.30
CK5A/CK5BE042 1050 700 33,800 17,600 15.50 11.70 31,600 15,000 3.50 3.60 18,200 6,200 2.36 1.58 8.20
CK5A/CK5BT036 1050 700 33,600 17,600 15.50 11.55 31,400 15,000 3.44 3.58 18,100 6,200 2.34 1.58 8.20
CK5A/CK5BT042 1050 700 33,600 17,600 15.50 11.65 31,400 15,200 3.46 3.56 18,100 6,200 2.36 1.58 8.20
CK5A/CK5BT048 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.50 3.60 18,200 6,200 2.38 1.60 8.30
CK5A/CK5BW036 1050 700 33,600 17,600 15.50 11.65 31,400 15,000 3.46 3.58 18,100 6,200 2.36 1.58 8.20
CK5PA036 1050 700 33,600 17,600 15.50 11.55 31,400 15,000 3.44 3.58 18,100 6,200 2.34 1.58 8.20
CK5PA042 1050 700 33,600 17,600 15.50 11.65 31,400 15,200 3.46 3.56 18,100 6,200 2.36 1.58 8.20
CK5PA048 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.50 3.60 18,200 6,200 2.38 1.60 8.30
CK5PE042 1050 700 33,800 17,600 15.50 11.70 31,600 15,000 3.50 3.60 18,200 6,200 2.36 1.58 8.20
CK5PT036 1050 700 33,600 17,600 15.50 11.55 31,400 15,000 3.44 3.58 18,100 6,200 2.34 1.58 8.20
CK5PT042 1050 700 33,600 17,600 15.50 11.65 31,400 15,200 3.46 3.56 18,100 6,200 2.36 1.58 8.20
CK5PT048 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.50 3.60 18,200 6,200 2.38 1.60 8.30
CK5PW036 1050 700 33,600 17,600 15.50 11.65 31,400 15,000 3.46 3.58 18,100 6,200 2.36 1.58 8.20
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 1050 700 33,400 17,400 15.50 11.60 31,000 14,800 3.42 3.52 17,800 6,100 2.32 1.56 8.10
CC5A/CD5AA042 1050 700 33,400 17,400 15.50 11.70 31,000 15,200 3.44 3.48 17,800 6,100 2.34 1.56 8.00
CC5A/CD5AC048 1050 700 33,000 17,200 15.50 11.60 30,400 14,600 3.34 3.48 17,600 6,100 2.32 1.56 8.00
CC5A/CD5AW036 1050 700 33,400 17,400 15.50 11.70 31,000 15,200 3.44 3.48 17,800 6,100 2.34 1.56 8.00
CC5A/CD5AW042 1050 700 33,600 17,400 15.50 11.80 30,800 14,800 3.50 3.54 17,900 6,100 2.36 1.56 8.20
CC5A/CD5AW048 1050 700 33,600 17,400 15.50 11.80 30,800 14,800 3.52 3.54 17,900 6,100 2.36 1.58 8.20
CD5AA048 1050 700 33,600 17,400 15.50 11.80 31,200 14,800 3.50 3.54 17,900 6,100 2.36 1.58 8.20
CE3AA036 1050 700 33,000 17,200 15.00 11.45 30,600 15,000 3.38 3.44 17,700 6,100 2.32 1.56 8.00
CE3AA042 1050 700 33,600 17,400 15.50 11.80 31,200 15,000 3.48 3.56 17,800 6,200 2.36 1.58 8.20
CE3AA048 1050 700 33,800 17,600 15.50 11.85 31,400 15,200 3.50 3.54 17,800 6,200 2.38 1.58 8.20
CK3BA036 1050 700 33,600 17,600 15.50 11.70 31,200 15,000 3.48 3.56 18,000 6,200 2.36 1.58 8.20
CK3BA042 1050 700 33,600 17,600 15.50 11.75 31,200 15,000 3.48 3.58 18,000 6,200 2.36 1.58 8.20
CK3BA048 1050 700 33,800 17,600 16.00 11.90 31,400 15,000 3.52 3.60 18,100 6,300 2.40 1.60 8.30
CK5A/CK5BA036 1050 700 33,600 17,600 15.50 11.65 31,200 15,000 3.46 3.56 18,000 6,300 2.36 1.58 8.20
CK5A/CK5BA042 1050 700 33,600 17,600 15.50 11.75 31,200 15,000 3.48 3.58 18,000 6,200 2.36 1.60 8.20
CK5A/CK5BA048 1050 700 33,800 17,600 16.00 11.90 31,400 15,000 3.52 3.60 18,100 6,300 2.40 1.60 8.30
CK5A/CK5BE042 1050 700 33,800 17,600 15.50 11.80 31,600 15,000 3.52 3.60 18,200 6,300 2.38 1.60 8.30
CK5A/CK5BT036 1050 700 33,600 17,600 15.50 11.65 31,200 15,000 3.46 3.56 18,000 6,300 2.36 1.58 8.20
CK5A/CK5BT042 1050 700 33,600 17,600 15.50 11.75 31,200 15,000 3.48 3.58 18,000 6,200 2.36 1.60 8.20
CK5A/CK5BT048 1050 700 33,800 17,600 16.00 11.90 31,400 15,000 3.52 3.60 18,100 6,300 2.40 1.60 8.30
UNIT
SIZE
SERIES
INDOOR
UNIT
Heating
HSPF
Cooling
High-Temp Low-Temp
CFM TC
SEER EER
TC Cop TC Cop
High Low
High Low
High Low High Low High Low High Low
COMBINATION RATINGS Continued
See notes on page 14.
