A180203
915SA
FURNACE SIZE
A B C D
SHIP WT.
LB (KG)
CABINET WIDTH OUTLET WIDTH BOTTOM INLET WIDTH AIR INTAKE
24026 14−3/16 (361) 12−1/2 (319) 12−9/16 (322) 7−1/8 (181) 118.0 (53.5)
30040
14−3/16 (361) 12−1/2 (319) 12−9/16 (322) 7−1/8 (181)
123.0 (55.9)
30060 127.0 (57.7)
36040
17−1/2 (445) 15−7/8 (403) 16 (406) 8−3/4 (222)
134.0 (60.9)
42060 144.0 (65.4)
48080 154.0 (70.0)
60080
21 (533) 19−3/8 (492) 19−1/2 (495) 10−1/2 (267)
161.5 (73.4)
42100 168.5 (76.6)
60100 168.5 (76.6)
60120
24−1/2 (622) 22−7/8 (581) 23 (584) 12−1/4 (311)
186.0 (84.5)
60140 190.0 (86.4)
Fig. 1 − Dimensional Drawing
915SA
