Table 9 – Air Delivery -- CFM (With Filter)
UNIT SIZE
RETURN-AIR
CONNECTION
SPEED
TAPS
2
EXTERNAL STATIC PRESSURE (IN. W.C.)
6
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
024026 SIDE/BOTTOM
Black 1000 945 895 835 775 705 635 560 485 395
Yellow 750 695 640 575 515 455 390 315 250 -
7
Blue 675 620 560 500 440 380 310 245 -
7
-
7
Red
5
500 440 375 315 245 -
7
-
7
-
7
-
7
-
7
030040 SIDE OR BOTTOM
Black 1100 1055 1010 960 905 850 795 740 685 620
Yellow 955 915 875 830 790 740 695 645 590 530
Blue 820 795 765 730 695 655 615 570 515 460
Red 730 710 680 655 625 595 555 515 465 400
036040 SIDE OR BOTTOM
Black 1245 1195 1150 1100 1050 1000 945 890 830 775
Yellow 1165 1120 1075 1030 980 925 870 815 760 710
Orange 1045 1015 965 925 885 840 790 740 695 640
Blue 1000 960 930 890 850 810 765 715 665 615
Red 735 725 700 680 650 625 590 555 515 470
030060 SIDE OR BOTTOM
Black 1340 1295 1245 1190 1130 1065 1005 895 815 725
Yellow 1035 1010 980 945 910 865 795 730 665 605
Blue 845 825 810 785 755 710 670 625 570 515
Red
5
770 750 730 710 675 640 600 560 510 455
042060 SIDE OR BOTTOM
Black 1665 1615 1550 1485 1420 1345 1270 1190 1105 985
Yellow 1340 1320 1295 1260 1215 1165 1110 1045 925 850
Orange 1050 1045 1035 1015 995 960 915 845 785 725
Blue 985 980 975 950 930 900 845 795 740 690
Red
5
735 720 700 675 650 620 595 560 520 480
048080 SIDE OR BOTTOM
Black 1870 1810 1740 1670 1600 1525 1440 1355 1270 1180
Yellow 1525 1495 1460 1415 1365 1305 1240 1170 1090 990
Orange 1375 1355 1330 1300 1260 1210 1155 1090 1025 940
Blue 1045 1040 1030 1010 985 960 920 875 825 745
Red
5
880 865 850 835 810 785 750 715 665 605
060080
BOTTOM or
TWO-SIDES
3,4
Black 2360 2250 2160 2065 1970 1880 1785 1685 1580 1455
Yellow 2100 2030 1960 1885 1805 1720 1635 1545 1440 1305
Orange 1840 1810 1765 1725 1665 1590 1515 1430 1335 1240
Blue 1705 1685 1660 1615 1570 1510 1445 1370 1280 1135
Red 1425 1410 1385 1365 1335 1290 1245 1190 1120 1050
042100 SIDE OR BOTTOM
Black 1750 1705 1660 1605 1545 1475 1405 1305 1220 1140
Blue 1550 1510 1470 1430 1380 1320 1245 1170 1095 1015
Yellow
5
1290 1255 1220 1180 1130 1075 1020 960 885 800
Red
5
1085 1045 1010 960 915 865 805 740 665 595
060100
BOTTOM or
TWO-SIDES
3,4
Black 2415 2330 2245 2155 2065 1965 1865 1760 1645 1530
Yellow 2130 2075 2010 1945 1865 1785 1695 1600 1490 1375
Orange 1830 1815 1785 1740 1685 1625 1550 1470 1370 1255
Blue 1690 1680 1655 1620 1580 1530 1465 1385 1295 1185
Red 1415 1405 1390 1370 1345 1305 1260 1200 1125 1050
060120
BOTTOM or
TWO-SIDES
3,4
Black 2440 2360 2295 2215 2105 1975 1815 1710 1575 1405
Blue 2300 2245 2185 2090 2005 1855 1745 1635 1505 1370
Yellow 1805 1780 1750 1705 1650 1595 1515 1430 1330 1230
Orange
5
1560 1550 1535 1505 1470 1420 1360 1285 1205 1130
Red
5
1390 1385 1370 1345 1320 1285 1230 1175 1105 1035
060140
BOTTOM or
TWO-SIDES
3,4
Black 2410 2325 2230 2135 2035 1930 1820 1700 1575 1445
Blue 2250 2175 2100 2020 1930 1825 1715 1600 1485 1370
Yellow
5
1740 1725 1700 1660 1610 1550 1470 1390 1295 1190
Orange
5
1500 1495 1485 1465 1435 1390 1335 1265 1185 1090
Red
5
1350 1345 1335 1315 1290 1255 1210 1150 1080 995
NOTE:
1. A filter is required for each return--- air inlet. Airflow performance includes a 3/4---in. (19 mm) washable filter media such as contained in a factory ---autho-
rized accessory filter rack. See accessory list. To determine airflow performance without this filter, assume an additional 0.1 in. w.c.. available external static
pressure.
2. Blower speed taps are not always in the same order. Factory default blower connections are as follows:
a. Heating airflow --- BLUE (also used for Continuous Fan)
b. Cooling airflow --- BLACK (enabled when the Y terminal is energized)
ADJUST THE BLOWER SPEED TAPS AS NECESSARY FOR THE PROPER AIR TEMPERATURE RISE FOR EACH INST ALLATION.
3. Airfl o ws over 1800 CFM require bottom return , two---side return, or bottom and side retu rn. A minimum filter size of 20” x 25” (508 x 635 mm) is required.
4. For upflow applications, air entering from one side into both the side of the furnace and a return air base counts as a side and bottom return.
5. Highlighted areas indicate that this airflow range is beyond the range allowed for heating. THESE AIRFLOW RA NGES MAY ONLY BE USED FOR COOL-
ING.
6. All airflows that are shown in BOLD exceed 0.58 watts per CFM at the given external static pressure.
7. The “--- ” entry indicates an unstable operating condition.
