A180203
915SA
FURNACE SIZE
A B C D
SHIP WT.
LB (KG)
CABINET WIDTH OUTLET WIDTH BOTTOM INLET WIDTH AIR INTAKE
24026 14--3/16 (361) 12--1/2 (319) 12--9/16 (322) 7--1/8 (181) 118.0 (53.5)
30040
14--3/16 (361) 12--1/2 (319) 12--9/16 (322) 7--1/8 (181)
123.0 (55.9)
30060 127.0 (57.7)
36040
17--1/2 (445) 15--7/8 (403) 16 (406) 8--3/4 (222)
134.0 (60.9)
42060 144.0 (65.4)
48080 154.0 (70.0)
60080
21 (533) 19--3/8 (492) 19--1/2 (495) 10--1/2 (267)
161.5 (73.4)
42100 168.5 (76.6)
60100 168.5 (76.6)
60120
24--1/2 (622) 22--7/8 (581) 23 (584) 12--1/4 (311)
186.0 (84.5)
60140 190.0 (86.4)
Fig. 1 -- Dimensional Drawing
915SA
