DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡
180BNA036A HI Outdoor Section With FE5ANB004 Indoor Section
1050
57 (13.9) 36.06 36.06 2.11 34.51 34.51 2.34 32.91 32.91 2.57 31.26 31.26 2.82 29.52 29.52 3.10 27.71 27.71 3.41
62 (16.7) 37.52 35.06 2.13 35.55 33.23 2.35 33.54 31.41 2.58 31.49 29.60 2.83 29.57 29.57 3.10 27.77 27.77 3.41
63 (17.2)†† 38.35 28.69 2.14 36.34 27.04 2.35 34.28 25.43 2.59 32.15 23.83 2.83 29.95 22.27 3.11 27.67 20.73 3.41
67 (19.4) 41.50 29.86 2.17 39.35 28.18 2.39 37.14 26.54 2.62 34.86 24.92 2.87 32.50 23.32 3.14 30.07 21.75 3.45
72 (22.2) 45.92 24.55 2.22 43.57 23.04 2.43 41.16 21.55 2.67 38.67 20.09 2.92 36.11 18.66 3.20 33.46 17.25 3.50
1125
57 (13.9) 36.99 36.99 2.13 35.39 35.39 2.35 33.73 33.73 2.58 32.01 32.01 2.84 30.21 30.21 3.12 28.34 28.34 3.43
62 (16.7) 38.07 36.50 2.14 36.06 34.60 2.36 34.02 32.71 2.59 32.06 32.06 2.84 30.26 30.26 3.12 28.38 28.38 3.43
63 (17.2)†† 38.90 29.69 2.15 36.84 28.01 2.36 34.71 26.35 2.60 32.54 24.72 2.84 30.29 23.12 3.12 27.96 21.53 3.42
67 (19.4) 42.07 30.93 2.18 39.87 29.22 2.40 37.60 27.53 2.63 35.27 25.87 2.88 32.86 24.23 3.15 30.39 22.63 3.46
72 (22.2) 46.54 25.25 2.23 44.13 23.71 2.44 41.65 22.19 2.68 39.12 20.70 2.93 36.50 19.24 3.21 33.79 17.80 3.51
1200
57 (13.9) 37.86 37.86 2.14 36.20 36.20 2.36 34.48 34.48 2.60 32.71 32.71 2.85 30.85 30.85 3.13 28.91 28.91 3.44
62 (16.7) 38.56 37.89 2.15 36.53 35.92 2.37 34.54 34.54 2.60 32.76 32.76 2.85 30.90 30.90 3.13 28.96 28.96 3.44
63 (17.2)†† 39.38 30.67 2.16 37.27 28.95 2.37 35.10 27.26 2.60 32.88 25.59 2.85 30.59 23.95 3.13 28.21 22.33 3.43
67 (19.4) 42.58 31.98 2.19 40.32 30.23 2.41 38.00 28.50 2.64 35.63 26.80 2.89 33.17 25.13 3.16 30.64 23.48 3.47
72 (22.2) 47.09 25.93 2.24 44.62 24.35 2.45 42.10 22.81 2.69 39.51 21.30 2.94 36.84 19.81 3.22 34.08 18.35 3.52
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡
180BNA036A LO Outdoor Section With FE5ANB004 Indoor Section
750
57 (13.9) 25.92 25.92 1.30 24.79 24.79 1.48 23.62 23.62 1.67 22.40 22.40 1.90 21.12 21.12 2.15 19.77 19.77 2.45
62 (16.7) 26.87 24.07 1.29 25.39 23.40 1.47 23.87 22.72 1.67 22.45 22.45 1.89 21.16 21.16 2.15 19.81 19.81 2.45
63 (17.2)†† 27.53 19.65 1.29 26.01 18.98 1.47 24.45 18.31 1.67 22.84 17.62 1.89 21.17 16.92 2.15 19.43 16.21 2.45
67 (19.4) 29.99 20.54 1.28 28.35 19.87 1.46 26.66 19.19 1.65 24.93 18.51 1.87 23.14 17.81 2.13 21.28 17.10 2.42
72 (22.2) 33.46 16.94 1.28 31.65 16.27 1.45 29.79 15.60 1.64 27.91 14.91 1.85 25.95 14.22 2.10 23.93 13.50 2.38
840
57 (13.9) 27.09 27.09 1.30 25.89 25.89 1.48 24.64 24.64 1.67 23.34 23.34 1.89 21.98 21.98 2.15 20.55 20.55 2.44
62 (16.7) 27.57 25.79 1.30 26.03 25.82 1.48 24.69 24.69 1.67 23.38 23.38 1.89 22.02 22.02 2.15 20.59 20.59 2.44
63 (17.2)†† 28.22 20.85 1.29 26.62 20.17 1.47 24.99 19.47 1.67 23.30 18.77 1.89 21.57 18.06 2.15 19.78 17.33 2.45
67 (19.4) 30.72 21.82 1.29 29.00 21.14 1.46 27.24 20.44 1.66 25.43 19.74 1.87 23.57 19.03 2.13 21.65 18.30 2.42
72 (22.2) 34.25 17.78 1.28 32.36 17.09 1.45 30.43 16.40 1.64 28.45 15.70 1.85 26.43 15.00 2.10 24.32 14.28 2.39
1000
57 (13.9) 28.87 28.87 1.30 27.54 27.54 1.48 26.16 26.16 1.67 24.74 24.74 1.89 23.25 23.25 2.14 21.69 21.69 2.43
62 (16.7) 28.92 28.92 1.30 27.59 27.59 1.48 26.21 26.21 1.67 24.78 24.78 1.89 23.28 23.28 2.14 21.73 21.73 2.43
63 (17.2)†† 29.16 22.90 1.30 27.45 22.19 1.48 25.72 21.47 1.68 23.94 20.74 1.90 22.13 20.00 2.16 20.27 19.23 2.46
67 (19.4) 31.72 24.02 1.30 29.88 23.31 1.47 28.00 22.59 1.66 26.10 21.87 1.88 24.15 21.13 2.13 22.15 20.37 2.43
72 (22.2) 35.34 19.19 1.29 33.32 18.48 1.46 31.27 17.77 1.65 29.19 17.05 1.86 27.05 16.33 2.10 24.85 15.59 2.39
187B / 180B
