5
ELECTRICAL DATA
MODEL
UNIT
S I Z E ---
SERIES
V --- P H --- H z
OPER
VOLTS*
COMPR FAN
MCA
MIN
WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
ft (m)}
MAX
LENGTH
ft (m)}
MAX
FUSE*
*or
CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60°C 75°C 60°C 75°C
187BNA
024--- A 208/230---1---60
253 197
52.0 10.30 0.7 13.6 14.00 14.00 60 (18.3) 57 (17.4) 20
036--- A 208/230---1---60 82.0 16.70 1.2 22.1 14.00 14.00 45 (13.7) 44 (13.4) 35
048--- A 208/230---1---60 96.0 21.20 1.3 27.8 12.00 12.00 51 (15.5) 49 (14.9) 40
060--- A 208/230---1---60 118.0 23.00 1.3 30.1 8.00 10.00 93 (28.3) 57 (17.4) 50
180BNA 036--- A 208/230---1 ---60 253 197 82.0 16.70 2.4 23.3 14.00 14.00 45 (13.7) 44 (13.4) 35
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non ---metallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336---26. If other than uncoated (no---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
} Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- Fu l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER (dBA)
UNIT SIZE
STANDARD
RATING (dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
187BNA024
* 7 1 --- l o w st a g e 53.0 62.0 64.5 66.5 63.0 60.5 52.5
7 2 --- h i g h s t a g e 54.0 61.5 66.5 66.5 63.5 60.5 55.5
187BNA036
* 7 2 --- l o w st a g e 54.0 61.5 66.5 68.0 63.5 60.5 53.5
7 2 --- h i g h s t a g e 54.5 61.5 67.5 68.0 62.0 59.5 54.5
187BNA048
* 7 2 --- l o w st a g e 54.5 63.0 67.0 67.0 64.5 61.0 56.5
7 3 --- h i g h s t a g e 55.0 63.0 68.0 67.5 63.5 62.0 57.5
187BNA060
* 7 3 --- l o w st a g e 56.5 62.0 67.5 69.5 64.5 60.0 53.5
7 3 --- h i g h s t a g e 55.0 62.0 67.0 68.5 64.5 60.0 53.5
180BNA036
* 7 2 --- l o w st a g e 55.5 58.5 64.0 67.0 64.5 59.5 53.5
7 2 --- h i g h s t a g e 56.5 60.0 66.0 66.0 60.0 56.5 53.0
NOTE: Tested in accordance with AHRI Standard 270---08. (Not listed with AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- SERIES
REQUIRED SUBCOOLING _F(_C)
187BNA024 --- A
10 (5.6)
187BNA036 --- A
10 (5.6)
187BNA048 --- A
10 (5.6)
187BNA060 --- A
10 (5.6)
180BNA036 --- A
10 (5.6)
187B / 180B
