37
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡
187BNA060---A HI Outdoor Section With CNPHP6124 Indoor Section
1500
57 (13.9) 54.27 54.27 3.61 52.74 52.74 3.98 50.95 50.95 4.38 49.05 49.05 4.82 46.81 46.81 5.30 44.25 44.25 5.83
62 (16.7) 57.18 48.11 3.64 55.08 47.35 4.01 52.75 46.48 4.40 50.22 45.51 4.83 47.39 44.39 5.31 44.31 44.31 5.84
63 (17.2)†† 58.34 39.49 3.65 56.17 38.66 4.02 53.77 37.73 4.41 50.96 36.64 4.84 48.16 35.56 5.32 44.84 34.30 5.84
67 (19.4) 63.05 41.02 3.70 60.68 40.18 4.07 58.06 39.24 4.47 55.17 38.22 4.90 51.93 37.06 5.38 48.34 35.79 5.90
72 (22.2) 69.52 33.78 3.78 66.88 32.88 4.15 63.98 31.88 4.55 60.75 30.78 4.98 57.17 29.57 5.46 53.18 28.23 5.99
1710
57 (13.9) 56.76 56.76 3.70 55.08 55.08 4.07 53.17 53.17 4.47 51.02 51.02 4.91 48.63 48.63 5.40 45.87 45.87 5.93
62 (16.7) 58.63 51.57 3.72 56.42 50.77 4.09 54.01 49.87 4.48 51.39 48.81 4.92 48.70 48.70 5.40 45.93 45.93 5.93
63 (17.2)†† 59.71 41.82 3.73 57.41 40.98 4.10 54.85 40.03 4.49 52.06 38.99 4.93 48.95 37.84 5.40 45.51 36.55 5.92
67 (19.4) 64.47 43.51 3.79 61.97 42.66 4.16 59.19 41.71 4.55 56.13 40.67 4.98 52.75 39.51 5.46 48.99 38.22 5.98
72 (22.2) 71.04 35.32 3.87 68.25 34.40 4.23 65.17 33.38 4.63 61.79 32.27 5.07 58.01 31.02 5.54 53.89 29.69 6.07
1835
57 (13.9) 58.06 58.06 3.76 56.29 56.29 4.13 54.30 54.30 4.53 52.08 52.08 4.97 49.55 49.55 5.45 46.68 46.68 5.98
62 (16.7) 59.38 53.53 3.77 57.14 52.72 4.14 54.70 51.76 4.53 52.14 52.14 4.97 49.58 49.58 5.45 46.74 46.74 5.98
63 (17.2)†† 60.37 43.15 3.78 58.00 42.29 4.15 55.37 41.34 4.54 52.51 40.30 4.97 49.24 39.10 5.44 45.83 37.85 5.96
67 (19.4) 65.16 44.93 3.84 62.57 44.07 4.20 59.71 43.12 4.60 56.59 42.08 5.03 53.13 40.91 5.50 49.31 39.62 6.03
72 (22.2) 71.76 36.19 3.92 68.89 35.26 4.28 65.74 34.24 4.68 62.28 33.12 5.11 58.42 31.86 5.59 54.21 30.52 6.11
2000
57 (13.9) 59.59 59.59 3.83 57.72 57.72 4.20 55.62 55.62 4.60 53.28 53.28 5.04 50.62 50.62 5.52 47.63 47.63 6.05
62 (16.7) 60.30 55.99 3.83 58.01 55.08 4.20 55.69 55.69 4.60 53.35 53.35 5.04 50.69 50.69 5.52 47.68 47.68 6.05
63 (17.2)†† 61.09 44.84 3.84 58.64 43.97 4.21 55.94 43.02 4.60 53.00 41.98 5.03 49.50 40.70 5.50 46.17 39.50 6.02
67 (19.4) 65.91 46.75 3.90 63.22 45.88 4.26 60.31 44.93 4.66 57.09 43.89 5.09 53.55 42.72 5.56 49.66 41.41 6.09
72 (22.2) 72.57 37.29 3.98 69.61 36.36 4.34 66.35 35.32 4.74 62.79 34.19 5.17 58.84 32.94 5.65 54.49 31.56 6.17
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡
187BNA060---A LO Outdoor Section With CNPHP6124 Indoor Section
1100
72 (22.2) 49.86 23.91 2.40 47.66 23.10 2.70 45.29 22.25 3.03 42.73 21.34 3.41 39.96 20.38 3.85 36.97 19.36 4.36
67 (19.4) 44.89 28.95 2.41 42.92 28.16 2.72 40.78 27.32 3.06 38.45 26.41 3.45 35.95 25.45 3.90 33.27 24.43 4.42
63 (17.2)†† 41.27 27.74 2.43 39.43 26.95 2.74 37.48 26.12 3.09 35.35 25.23 3.48 33.05 24.28 3.94 30.59 23.28 4.47
62 (16.7) 40.39 33.88 2.43 38.64 33.10 2.74 36.73 32.25 3.09 34.69 31.33 3.49 32.55 32.36 3.95 30.57 30.57 4.47
57 (13.9) 38.60 38.60 2.44 37.27 37.27 2.75 35.79 35.79 3.10 34.18 34.18 3.49 32.43 32.43 3.95 30.51 30.51 4.47
1250
72 (22.2) 51.05 25.10 2.43 48.73 24.28 2.72 46.25 23.41 3.05 43.54 22.47 3.43 40.66 21.49 3.87 37.55 20.44 4.38
67 (19.4) 46.00 30.83 2.44 43.91 30.02 2.74 41.67 29.15 3.08 39.23 28.22 3.47 36.62 27.24 3.91 33.83 26.20 4.44
63 (17.2)†† 42.33 29.50 2.45 40.40 28.69 2.76 38.35 27.84 3.11 36.05 26.90 3.50 33.72 25.95 3.96 31.15 24.92 4.49
62 (16.7) 41.54 36.44 2.45 39.68 35.60 2.76 37.75 34.70 3.11 35.78 35.78 3.50 33.89 33.89 3.95 31.81 31.81 4.47
57 (13.9) 40.50 40.50 2.46 39.05 39.05 2.77 37.46 37.46 3.11 35.73 35.73 3.50 33.84 33.84 3.95 31.76 31.76 4.47
1400
72 (22.2) 51.99 26.23 2.45 49.57 25.39 2.75 46.98 24.50 3.08 44.19 23.56 3.45 41.20 22.55 3.89 37.99 21.49 4.40
67 (19.4) 46.87 32.63 2.46 44.69 31.80 2.76 42.36 30.92 3.10 39.84 29.97 3.49 37.15 28.97 3.93 34.27 27.90 4.45
63 (17.2)†† 43.18 31.19 2.47 41.18 30.37 2.78 39.04 29.50 3.13 36.72 28.56 3.52 34.24 27.56 3.98 31.59 26.49 4.51
62 (16.7) 42.54 38.84 2.48 40.71 40.48 2.78 38.96 38.96 3.13 37.09 37.09 3.51 35.06 35.06 3.96 32.84 32.84 4.48
57 (13.9) 42.13 42.13 2.48 40.58 40.58 2.78 38.89 38.89 3.13 37.02 37.02 3.51 35.01 35.01 3.96 32.80 32.80 4.48
1500
72 (22.2) 52.50 26.95 2.47 50.03 26.11 2.76 47.39 25.21 3.09 44.54 24.25 3.47 41.49 23.24 3.90 38.22 22.17 4.41
67 (19.4) 47.35 33.80 2.48 45.12 32.96 2.78 42.74 32.06 3.12 40.18 31.10 3.50 37.44 30.08 3.95 34.52 28.99 4.47
63 (17.2)†† 43.66 32.29 2.49 41.61 31.45 2.80 39.42 30.56 3.14 37.05 29.60 3.53 34.53 28.59 3.99 31.85 27.50 4.52
62 (16.7) 43.23 43.01 2.49 41.55 41.55 2.80 39.79 39.79 3.14 37.85 37.85 3.52 35.74 35.74 3.97 33.45 33.45 4.48
57 (13.9) 43.11 43.11 2.49 41.49 41.49 2.80 39.73 39.73 3.14 37.79 37.79 3.52 35.69 35.69 3.97 33.40 33.40 4.48
187B / 180B
