Table 10 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Sizes 24--60 208/230VAC -- 1 Phase (Cont.)
Unit
Size
Heating Rise
Range
o
F(
o
C)
Motor
Speed
Wire
Color
External Static Pressure (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
48090
35 --- 65
( 1 9 --- 3 6 )
Low
1
Blue
CFM 1378 1344 1295 1260 1216 1179 1135 1087 1035 995 BHP 0.26 0.27 0.29 0.31 0.31 0.33 0.34 0.36 0.36 0.38 Heat Rise (
o
F) 49 50 52 54 56 57 60 62 65 NA
Heat Rise (
o
C) 27 28 29 30 31 32 33 35 36 NA
M e d --- L o w
2
Pink
CFM 1696 1671 1631 1607 1574 1539 1507 1463 1432 1393 BHP 0.45 0.47 0.49 0.50 0.52 0.52 0.54 0.55 0.57 0.58 Heat Rise (
o
F) 40 40 41 42 43 44 45 46 47 49
Heat Rise (
o
C) 22 22 23 23 24 24 25 26 26 27
Medium
3
Red
CFM 1994 1968 1943 1910 1882 1835 1774 1702 1614 1512 BHP 0.72 0.73 0.75 0.76 0.78 0.78 0.76 0.73 0.70 0.66 Heat Rise (
o
F) NA NA 35 35 36 37 38 40 42 45
Heat Rise (
o
C) NA NA 19 20 20 20 21 22 23 25
M e d --- H i g h Orange
CFM 2054 2013 1986 1964 1919 1854 1779 1695 1605 1498 BHP 0.77 0.79 0.80 0.82 0.81 0.80 0.76 0.74 0.69 0.65 Heat Rise (
o
F) NA NA NA NA 35 36 38 40 42 45
Heat Rise (
o
C) NA NA NA NA 20 20 21 22 23 25
High Black
CFM 2267 2201 2133 2071 1997 1923 1835 1739 1654 1551 BHP 1.03 1.00 0.97 0.93 0.89 0.86 0.82 0.78 0.74 0.69 Heat Rise (
o
F) NA NA NA NA NA 35 37 39 41 44
Heat Rise (
o
C) NA NA NA NA NA 20 20 22 23 24
48115
30 --- 60
( 1 7 --- 3 3 )
Low
3
Blue
CFM 1378 1344 1295 1260 1216 1179 1135 1087 1035 995 BHP 0.26 0.27 0.29 0.31 0.31 0.33 0.34 0.36 0.36 0.38 Heat Rise (
o
F) NA NA NA NA NA NA NA NA NA NA
Heat Rise (
o
C) NA NA NA NA NA NA NA NA NA NA
M e d --- L o w
2
Pink
CFM 1696 1671 1631 1607 1574 1539 1507 1463 1432 1393 BHP 0.45 0.47 0.49 0.50 0.52 0.52 0.54 0.55 0.57 0.58 Heat Rise (
o
F) 51 52 53 54 55 56 57 59 60 NA
Heat Rise (
o
C) 28 29 29 30 31 31 32 33 34 NA
Medium
1
Red
CFM 1994 1968 1943 1910 1882 1835 1774 1702 1614 1512 BHP 0.72 0.73 0.75 0.76 0.78 0.78 0.76 0.73 0.70 0.66 Heat Rise (
o
F) 43 44 44 45 46 47 49 51 54 57
Heat Rise (
o
C) 24 24 25 25 26 26 27 28 30 32
M e d --- H i g h Orange
CFM 2054 2013 1986 1964 1919 1854 1779 1695 1605 1498 BHP 0.77 0.79 0.80 0.82 0.81 0.80 0.76 0.74 0.69 0.65 Heat Rise (
o
F) 42 43 44 44 45 47 49 51 54 58
Heat Rise (
o
C) 23 24 24 24 25 26 27 28 30 32
High Black
CFM 2267 2201 2133 2071 1997 1923 1835 1739 1654 1551 BHP 1.03 1.00 0.97 0.93 0.89 0.86 0.82 0.78 0.74 0.69 Heat Rise (
o
F) 38 39 41 42 43 45 47 50 52 56
Heat Rise (
o
C) 21 22 23 23 24 25 26 28 29 31
