Bryant QUANTUM PLUS 650A User Manual

—2—
DIMENSIONS
A94148
ACCESS
PANEL
1
1
/4
"

1. Allow 30 in.
clearance to service end of unit, 48 in. above unit, 6 in. on one side, 12 in. on remaining side,
and 24 in. between units for proper airflow. Minimum outdoor operating ambient in cooling mode is 55°F (unless low ambient control is used) max 125°F.2. Maximum outdoor operating ambient in heating mode is 66°F.3. Series designation is the 14th position of the unit model number.4. Center of gravity .5.
NOTES:
AIR DISCHARGE
AIR DISCHARGE
AIR IN
AIR IN
AIR IN
2
1
/2
"
AIR DISCHARGE
1
3
/4
"
4
"
3
/8 IN.
DIA LIQUID
LINE CONN
H
DIA SUCTION
LINE CONN
8
3
/16
"
7
/8 IN.
DIA HOLE
FIELD POWER SUPPLY CONN
7
/8 IN.
DIA (22.22)
HOLE WITH 1
1
/8 IN.
DIA (34.92) KNOCKOUT
AND 1
3
/8 IN.
DIA KNOCKOUT
3
/8 IN.
DIA (9.5) TIEDOWN KNOCKOUTS
(2) PLACES IN BASEPAN
10
1
/2
"
FIELD CONTROL SUPPLY CONN  
1
9
/16
"
L
C
F
N
G
A
B
M
K
E
D
C
L
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS
MINIMUM MOUNTING
PAD DIMENSIONS
A B C D E F G H K L M N Support Feet Snow Stand
024 A,C 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 5/8 15-7/8 14-3/8 14-1/4 2-15/16 26 x 32 31 x 35 030 A,C 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 3/4 14 13-1/8 13-3/4 2-15/16 26 x 32 31 x 35 036 A,C 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 3/4 16-1/8 14-1/8 13-1/4 2-15/16 26 x 32 31 x 35 042 A,C 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 7/8 16-1/4 14 13-1/8 2-15/16 26 x 32 31 x 35 048 A,C 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16-1/4 14-1/4 14-1/2 2-15/16 26 x 32 31 x 35 060 B,C 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16 13-3/4 14 2-15/16 26 x 32 31 x 35
