SPECIFICATIONS
See notes on page 5.
UNIT SIZE-SERIES 024-A,C 030-A,C 036-A,C
Operating Weight (Lb) 214 205 217
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor Rated Load Amps 15.1 14.7 15.4
Compressor Locked Rotor Amps 61.0 72.5 83.0
Condenser Fan Motor—Full Load Amps 0.8 1.1 1.1
Minimum Unit Ampacity for Wire Sizing 19.7 19.5 20.4
Minimum Wire Size (60°C Copper) (AWG)† 14 14 12
Minimum Wire Size (75°C Copper) (AWG)† 14 14 12
Maximum Wire Length (60°C) (Ft)‡ 39 39 60
Maximum Wire Length (75°C) (Ft)‡ 37 37 57
Maximum Branch Circuit Fuse Size** 30 30 30
COMPRESSOR & REFRIGERANT
Compressor Manufacturer Copeland
Compressor Type Scroll
Refrigerant Type Puron
Refrigerant Amount (Lb)†† 7.18 6.63 8.87
OUTDOOR COIL & FAN
Coil Face Area (Sq Ft) 18.18 15.15 12.12
Fins per In.—Rows—Circuits 25—1—2 25—1—3 20—2—3
Fan Motor—HP & RPM 1/8 and 825 1/5 and 825 1/5 and 825
Rated Airflow (CFM) 2400 2800 2800
OPTIONAL EQUIPMENT
Support Feet—4 In. (4) KSASF0101AAA
Snow Stand—18 In. KHASS0206MPK
Time Delay Relay KAATD0101TDR
Interface Control (Energy Minder)‡‡ KHAIC0101AAA
Service Alarm*** KHASA0101AAA
Outdoor Thermostat KHAOT0301FST
Secondary Outdoor Thermostat KHAOT0201SEC
Crankcase Heater KAACH1201AAA
Start Assist—Capacitor/Relay Type KSAHS1501AAA
Start Assist—PTC Type Standard
Bi-Flow TXV (Hard Shutoff) KSATX0201HSZ KSATX0301HSZ
Filter Drier (Suction Line) KH45LG140 (RCD)
Evaporator Freeze Thermostat††† KAAFT0101AAA
Isolation Relay††† KHAIR0101AAA
Liquid-Line Solenoid Valve (LSV) KHALS0401LLS
Low-Ambient Pressure Switch KSALA0301410
