BSC BSV10 - Page 23

Table 5 Main replaceable parts list for BSV30/BSV40
Location
Description
Specifications
Material
Qty
Coupling
Coupling Spider
--------
NBR
1
Shaft
Oil seal
TCV244008
NBR
3
Exhaust valve
First exhaust valve plate
--------
SUS
1
Second exhaust valve plate
--------
SUS
1
Cylinder
0-ring
S8, JIS
FKM
4
0-ring
S18, JIS
NBR
1
0-ring
S70, JIS
NBR
1
0-ring
S105, JIS
NBR
3
0-ring
P40, JIS
NBR
1
0-ring
A-267, AS568
NBR
1
Plug
0-ring
P18, JIS
NBR
1
0-ring
P36, JIS
NBR
1
Inlet port
0-ring
V55, JIS
NBR
1
Outlet port
0-ring
P46, JIS
NBR
1
Oil level gauge
0-ring
77.5X3.55, C
FKM
1
Oil plug
Gasket
15X22X2
NBR
3
Table 6 Main replaceable parts list for BSV60/BSV90
Location
Description
Specifications
Material
Qty
Coupling
Coupling Spider
--------
NBR
1
Shaft
Oil seal
TCV244008
NBR
3
Exhaust valve
First exhaust valve plate
--------
SUS
2/3
Second exhaust valve plate
--------
SUS
1
Cylinder
0-ring
S8, JIS
FKM
4
0-ring
S18, JIS
NBR
1
0-ring
S70, JIS
NBR
1
0-ring
S120, JIS
NBR
3
0-ring
P48, JIS
NBR
1
0-ring
A-274, AS568
NBR
1
Plug
0-ring
P18, JIS
NBR
1
0-ring
P36, JIS
NBR
2/3
Inlet port
0-ring
V70, JIS
NBR
1
Outlet port
0-ring
P46, JIS
NBR
1
Oil level gauge
0-ring
77.5X3.55, C
FKM
1
Oil plug
Gasket
15X22X2
NBR
3
Location
Description
Specifications
Material
Qlty
Coupling
Coupling Spider
GR28
NBR
1
Shaft
Oil seal
TCV244008
NBR
3
First exhaust
SUS
1
Exhaust valve
valve plate
Second exhaust
valve plate
SUS
1
Cylinder
0_ring
A-267
NBR
1
0_ring
P40, JIS
NBR
1
0_ring
S8, JIS
NBR
4
0_ring
S18, JIS
NBR
1
0_ring
S70, JIS
NBR
1
0_ring
S105, JIS
NBR
3
Plug
0_ring
P18, JIS
NBR
1
0_ring
P36, JIS
NBR
1
lnlet port
0_ring
V55, JIS
NBR
1
Outlet port
0_ring
P46, JIS
NBR
1
Oil level gauge
0_ring
77.5x3.55, C
NBR
1
Oil drain plug
Gasket
22x16x3
NBR
3
Location
Description
Specifications
Material
Qlty
Coupling
Coupling Spider
GR28
NBR
1
Shaft
Oil seal
TCV244008
NBR
3
First exhaust
SUS
1
Exhaust valve
valve plate
Second exhaust
valve plate
SUS
1
Cylinder
0_ring
A-267
NBR
1
0_ring
P40, JIS
NBR
1
0_ring
S8, JIS
NBR
4
0_ring
S18, JIS
NBR
1
0_ring
S70, JIS
NBR
1
0_ring
S105, JIS
NBR
3
Plug
0_ring
P18, JIS
NBR
1
0_ring
P36, JIS
NBR
1
lnlet port
0_ring
V55, JIS
NBR
1
Outlet port
0_ring
P46, JIS
NBR
1
Oil level gauge
0_ring
77.5x3.55, C
NBR
1
Oil drain plug
Gasket
22x16x3
NBR
3
