5.%DMX%connection%and%DMX%protocol%
!
5.1!DMX!addressing:! !
!
5.1.1!The!device!is!controlled!by!universal!DMX!512!protocol,!DMX!address!is!the!start!chan n el!used!to!receive!
instructio n s!fro m!the!external!controller.!For!independent!control,!each!fixture!must!be!as sign ed !its!unique!address!
control!channels.!For!example,!this!device!has!four!channel!modes:!31/32/18/20,!if!we!se t !th e !mode!a t!s ta n d a r d !31!
channels!mode,!and!there!are!several!models!need!to!be!independently!controlled,!we!just!simply!address!first!fixture!
at!1,!and!second!fixture!at!32,!third!on e !a t!63,!etc.! !
If!the!dev ice s !h av e!the!same!add ress,!they!will!behave!synchronically.! !
DMX!addressing!is!limited,!don’t!set!the!address!so!high!that!without!enough!control!chann els!for!the!fixtures.!
Display!is!flashing!when!no!DMX!signal!is!received.!
!
5.1.4!Connection:!us!DMX!cable!with!5!pin!XLR-plugs!to!connect!the!controller!with!the!f ixture!or!one!fixtu re!with!
another.!
