FEATURES
• High-performance BST speaker with high-precision sound reproduction thanks to high-quality compo-
nents, including 3 digital ampliers and a DSP.
• 12"/30cm or 15" /38cm Woofer 400W RMS
• Ideal for stage, bar, concert, disco...
• Fitted with 3x class D ampliers (400W + 2x 200W RMS)
• DSP with 2 preset sounds
• 2 XLR Line in- & outputs
• Signal indicator and limiter
• Plywood cabinet with black heavy-duty textured paint
Rear Panel
1. POWER LED: Lights up when the box is switched on
LIMIT LED: This LED lights up when the volume reaches a dangerous level for the speakers. Please reduce
the volume immediately to protect the speakers.
SIGNAL LED: Lights up when the inputs are receiving a signal
2. Input signal level control for line input 1
Turn to adjust the volume of input 1 to the desired level.
3. Line input 2 input level control
Turn to adjust the volume of input 2 to the desired level.
4. XLR line inputs: Balanced XLR inputs for connecting sources such as mixers, instruments or microphones.
5. XLR line outputs: Send the signal from inputs 1 and 2 to another loudspeaker or subwoofer.
6. DSP mode indicator: Lights up the selected DSP
7. DSP Mode Selector: Press to cycle through the 2 preset modes
8. ON/OFF switch
9. Mains input: Connect the supplied mains cable to a suitable wall socket.
SPECIFICATIONS
Model BMT312 BMT315
Input power 100-240V~ 50/60Hz
RMS power 1x 400W + 2x 200W
Magnets Woofer: 60oz, midrange: 30oz,
tweeter: 22oz
Woofer: 80oz, midrange: 30oz,
tweeter: 22oz
Voice coils Woofer: 3’’-75,5mm; midrange: 1,5’’-38,6mm
Sensitivity 1W/1m 96dB 97dB
Max. SPL 130dB 131dB
Dimensions 380 x 360 x 740mm 440 x 420 x 800mm
Weight 26kg 32kg
6 • BMT312 / BMT315
