Introduction
1
■ What is the display showing
1 2 3 4 -- -- -- --
15/07/03 14:22
1 2 3 4 -- -- -- --
1 2 3 4 -- -- -- --
15/07/03 14:22
System off,
e.g.: zones 1, 2, 3, 4 active
System on,
e.g.: zones 1 and 4 enabled,
zones 2 and 3 disabled
System off,
Technical alarm signal
■ The display
 Initial page
1 2 3 4 -- -- -- --
15/07/03 14:22
1 2 3 4 -- -- -- --
ZONES
1 :Entrance
2 :Perimeter
3:Night
Exclude
System zones
(Max 8 zones)
Date and
hour
on/off indication
Technical indications
Alarm signal zone
 In case of an alarm
 Edit menu
Functions
Active zones
Disabled zones
