KNX temperature control panel
12. COMMUNICATION OBJECTS CONTINUED
12.1 List of objects (continued)
No. Function Object name Size Flags
13 Heating/Cooling Cooling mode 1.002 (1 bit) CW
Cooling mode active received from the bus
Only in 2-tube installations
1 = Cooling mode
0 = Cooling mode not active (default value)
14 Heating/Cooling Heating mode 1.002 (1 bit) CW
Heating mode active received from the bus
Only in 2-tube installations
1 = Heating mode active
0 = Heating mode not active (default value)
15 Heating/Cooling Heating valve status 5.001 (1 byte) CW
Heating valve open (%) received from the bus
Only in 4-tube installations
Default value = 0
16 Heating/Cooling
Cooling (Heating/Cooling) valve status
5.001 (1 byte) CW
In 4-tube installation: Cooling valve open (%) received from the bus
In 2-tube installation: Cooling (if OBJ13 cooling mode = 1) valve open (%) or Heating valve open (%) received from the bus
Default value = 0
17 Heating/Cooling Heating valve status 1.002 (1 bit) CW
Heating valve open received from the bus
Only in 4-tube installations
1 = Heating valve open
0 = Heating valve closed (default value)
18 Heating/Cooling Cooling (Heating/Cooling) valve status 1.002 (1 bit) CW
In 4-tube installation: Cooling valve open received from the bus
In 2-tube installation: Cooling (if OBJ13 cooling mode = 1) or Heating valve open received from the bus
1 = Cooling (Heating/Cooling) valve open
0 = Cooling (Heating/Cooling) valve closed (default value)
19 Fan Fan Speed 5.001 (1 byte) CT
Fan speed (%) sent on the bus
Only if 1-byte Fan function is active
Default value = 0
20 Fan Fan Speed 1 1.002 (1 bit) CT
Fan speed 1 sent on the bus
Only if 1-bit Fan function is active
1 = Fan speed 1
0 = Fan speed off (default value)
21 Fan Fan Speed 2 1.002 (1 bit) CT
Fan speed 2 sent on the bus
Only if 1-byte Fan function is active
1 = Fan speed 2
0 = Fan speed off (default value)
22 Fan Fan Speed 3 1.002 (1 bit) CT
Fan speed 3 sent on the bus1 = Standby
Only if 1-bit Fan function bit is active
1 = Fan speed 3
0 = Fan speed off (default value)
