BUBBA burger CBC1844F - Grill Components and Tools; Parts List; Hardware List; Required Assembly Tools

3
Expanded View
Parts List
1
Lid Air Vent B0105-A00
2
Temperature Gauge B0104-H01
3
Lid C1841-010
4
Temperature Gauge Support C0722-010
5
Lid Handle C1841-020
6
Left Top Hinge C2205-010
7
Right Top Hinge C2205-020
8
Left Bottom Hinge C2205-030
9
Right Bottom Hinge C2205-040
10
Warming Rack C2204-010
11
Cooking Grid C1841-070
12
Charcoal Grid C1744-010
13
Bottom Bowl C1841-080
14
Lock B0107-M01
15
Ash Receiver C1744-020
16
Ash Receiver Handle* C1744-030
17
Ash Receiver Slide C1744-040
18
Bottom Bowl Air Vent C1744-050
19
Rear Leg (2) C1841-090
20
Front Leg (2) C1841-100
21
Bottom Mesh C1841-110
22
Foot (2) B0305-L01
23
Wheel (2) B0302-E01
24
Brand Plate* B0109-BC0
* Pre-assembled
A
Screw
M4x10 Nickel Plated
8 pcs
B
Screw
M6x14 Nickel Plated Phillips Truss Head
18 pcs
C
Nut
M8 Nickel Plated
2 pcs
D
Wing Nut
M4 Nickel Plated
2 pcs
E
Wing Nut
M6 Nickel Plated
22 pcs
F
Washer
ø6.4 Aluminium
20 pcs
G
Washer
ø22 Nickel Plated
2 pcs
H
Lock Washer
ø6.4 Nickel Plated
20 pcs
I
Pin
ø5x 45 Nickel Plated
2 pcs
J
Cotter Pin
ø1.4 x 30 Black
2 pcs
Tools Required for Assembly (Included)
#2 Phillips Head Screwdriver 1 pc
M8 Wrench 1 pc
Hardware
6
14
11
15
7
5
2
1
22
19
17
20
2321
16
9
8
10
12
13
18
3
4
19
20
22
24
23
