Model 22: 4" (100mm) deep Table 8
Output BTU/hr
Supply 194°F (90°C) 176°F (80°C) 158°F (70°C) 140°F (60°C) Part Number
Delta T 36°F (20°C) 36°F (20°C) 18°F (10°C) 18°F (10°C)
12"x16"x4"
1600 1300 1100 800 3-21216
12"x24"x4"
2400 1900 1700 1200 3-21224
12"x36"x4"
3700 2900 2500 1800 3-21236
12"x48"x4" 4900 3800 3400 2400 3-21248
12"x63"x4" 6500 5100 4500 3300 3-21263
12"x71"x4" 7300 5800 5100 3700 3-21271
20"x16"x4" 2500 2000 1700 1200 3-22016
20"x24"x4" 3700 2900 2600 1900 3-22024
20"x36"x4" 5600 4400 3900 2800 3-22036
20"x48"x4" 7500 5900 5200 3700 3-22048
20"x59"x4" 9300 7300 6400 4600 3-22059
20"x71"x4" 11200 8800 7800 5600 3-22071
24"x16"x4" 2900 2300 2000 1400 3-22416
24"x24"x4" 4300 3400 3000 2200 3-22424
24"x36"x4" 6500 5100 4500 3200 3-22436
24"x48"x4" 8700 6800 6000 4300 3-22448
24"x59"x4" 10800 8400 7400 5300 3-22459
24"x71"x4" 13000 10200 9000 6500 3-22471
36"x16"x4" 3500 2700 2400 1700 3-23616
All values based on 68°F (20°C) room temperature.
