Buderus 21 - Pressure Drop Curves

3 0
|
Panel Radiator
Design Manual
Panel Radiator Design Manual | 12.2009
Technical specications are subject to change without prior notice
Pressure drop curves:
Settings on flowsetter
1 2 3 4 5 6 7 N
200
100
90
80
70
60
50
40
30
20
10
9
8
7
6
5
4
Pressure Drop in Inches H 0
²
0.05 0.08 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.9 1 2 3
GPM
BTU/Hr
BTU/Hr
500 1,000 2,000 5,000 10,000
BTU/Hr
750 1,500 3,000 7,500 15,000
1,000 2,000 4,000 10,000 20,000
∆T = 40°F (20°C)
∆T = 20°F (10°C)
∆T = 30°F (15°C)
Fig. 13
