Plumbing Connection
Water Connection
Note - Plumbing connections must be made in such way that will allow the machine to be
removed for service and cleaning.
1. Connect the hose supplied with the machine to the inlet at the rear of the machine and
the ¾” NPT fitting on the water supply line.
2. Check the water inlet pressure is between 2-4 bar (29-58 psi) (not static). If it is more a
PRV (pressure reducing valve) must be installed. If it is less a booster pump will be
required
Drain Connection
1. Connect the drain hose supplied to the main drainage pipe work.
