Buffalo DW467 - Converting Single phase 30 A to Single Phase 13 A

Converting Single phase 30A to Single Phase 13A
1. REMOVE THE TWO RED CABLES FROM THE LEFT SIDE AND THE TWO WHITE
CABLES FROM THE RIGHT SIDE OF THE HEATING ELEMENT OF THE BOILER.
2. REMOVE THE TWO RED CABLES FROM THE CONTACT 1L1 AND THE TWO
WHITE CABLES FROM THE CONTACT 5L3 OF THE MAGNETIC CONTACTOR.
CHANGE THE POSITION OF THE BLUE CABLE FROM THE CONTACT 13NO TO 5
L3
3. REPLACE THE POWER SUPPLY CABLE FROM 3X10mm2 TO 3X1,5mm2
Power
Supply Cable
3 x 1.5mm2
Power
Supply Cable
3 x 10mm2
