Parts ListV22
Page 13
Hardware
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 45.0000 PC NAIL;CROWN:2mm2;WIDTH:1mm27;THICKNESS:1mm0;LENGTH:25
mm;18-GAUGE (0.49*0.40) FINISH;GALVANIZED
*NOT available in DP
2 45.0000 PC NAIL;CROWN:2mm2;WIDTH:1mm27;THICKNESS:1mm0;LENGTH:30
mm;18-GAUGE (0.49*0.40) FINISH;GALVANIZED
*NOT available in DP
3 55.0000 PC NAIL;STAPLE;CROWN
10mm;LEGLENGTH:10mm;WIDTH:1.2mm;THICKNESS:0mm6;FINISH:
GALVANIZED
*NOT available in DP
4 110.0000 PC NAIL;STAPLE;CROWN
10mm;LEGLENGTH:6mm;WIDTH:1.2mm;THICKNESS:0mm6;FINISH:G
ALVANIZED
*NOT available in DP
5 8.0000 PC CABLE TIE;NYLON;4in;COLOR: *NOT available in DP
6 1.0000 PC WIRECLAMP;LUG:4mm4;LENGTH:56mm;OUTER DIA;8mm;PLASTIC
COVERED STEEL;COLOR:BLK
*NOT available in DP
7 1.4360 G SCREWLOCK;SPEC.NO:01090 *NOT available in DP
8 4.0000 PC NUT;M;3 MM;3.2 MM;HEX WASHER;7.3 MM;ZINC;BLUE;HEXAGON
REC.;0.5 MM;M3*0.5mm NUT WITH TEETH EXTERNAL WASHER
*NOT available in DP
9 2.0000 PC HEX.NUT T-NUT;11.11 MM;4 MM;17 MM;NICKEL;SILVER;OCT.
NUT;7/16" x G20
*NOT available in DP
10 24.0000 PC T-NUT;INNER DIA;M4mm;W/PRONG;SURFACE:ZINC/BLACK *NOT available in DP
11 1.0000 PC HEX. NUT;INNER DIA;M4mm;SURFACE:ZINC *NOT available in DP
12 4.0000 PC HEX. NUT;INNER DIA;M5mm;SURFACE:ZINC *NOT available in DP
13 8.0000 PC T-NUT;INNER
DIA;M5mm;THICK:8mmW/PRONG;SURFACE:ZINC;COLOR:BLACK
*NOT available in DP
14 9.0000 PC HEX.
NUT;THREAD:9mm;THICKNESS:2mm;PITCH:0mm75;SURFACE:NICKE
L;(PHONE JACK)
*NOT available in DP
15 5.0000 PC OCT. NUT;FOR
JACK;3/8in;OCTWRENCH:14.5mm;THICKNESS:3.5mm;SURFACE:NICK
EL/SILVER
*NOT available in DP
16 2.0000 PC STEEL ROUND NUT WITH HOLE;INNER
DIA;12mm;M12;ROUND;PITCH=0.75mm;SURFACE:ZINC
*NOT available in DP
17 1.0000 PC HEX. NUT;INNER DIA:13mm;SURFACE:ZINC *NOT available in DP
18 5.0000 PC F87-00100-13260 12AX7 GROMMET;P0806;DST.NO:001;DPT.NO:13260;(P0806-
12AX7_GROMMET-REVA.DWG)
USE UP STOCK.
19 2.0000 PC V87-00200-10103 F87-00200-10103 RUBBER BUSHING;I00172P;DST.NO:002;DPT.NO:10103;(I00172P-
RUBBER_BUSHING-REVB.dwf)
20 2.0000 PC F87-01000-12070 PAD;RUBBER;6mm*2mm5;COLOR:BLK;DWG.NO:12070;(R14-GUITAR-
RUBBERPAD-REVB.DWG)
21 21.0000 PC SCREW;A;4 MM;13 MM;PAN;ZINC;BLACK;2.84 MM;SC;A4*13mm *NOT available in DP
22 2.0000 PC SCREW;M3mm*3mm;HEAD:PAN WASHER DIA
4mm5;INSERT:PHILIPS REC.;SURFACE:BLACK/ZINC
*NOT available in DP
23 12.0000 PC SCREW;M3mm*4mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
24 1.0000 PC SCREW;M3mm*6mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:NICKEL
*NOT available in DP
25 15.0000 PC SCREW;M3mm*6mm;HEAD:PAN;INSERT:PHILLIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
26 4.0000 PC SCREW;M3mm*6mm;PITCH:0mm5;HEAD:FLAT;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
27 1.0000 PC SCREW;M3mm*7mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
28 4.0000 PC SCREW;BT3mm*8mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:ZINC
*NOT available in DP
29 2.0000 PC SCREW;M3mm*9mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
