Bugera V22 - Page 15

Parts ListV22
Page 15
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
61 0.1240 G F97-00100-02478 PAPER,KRAFT;WIDTH:300mm;THICKNESS:0mm05
62 1.0000 PC F97-00100-14822 PLASTIC;I00512P;COVER
SHEET;DST.NO:001;DPT.NO:14822;(I00512P-COVER_SHEET-REVA)
63 1.0000 PC F97-00100-14964 MI;INSULATION SHEET;P0803;DST.NO:001;DPT.NO:14964;(P0803-
INSULATION_SHEET-REVA.DWG)
64 2.0000 PC F97-00100-15426 PA-P0803/PAPERBOARD_A;DST.NO:001;DPT.NO:15426;(REVA)
65 2.0000 PC F97-00100-15427 PA-P0803/PAPERBOARD_B;DST.NO:001;DPT.NO:15427;(REVA)
66 1.0000 PC F97-17000-04145 SHEET;FOAM;FOOTSWITCH;FS112;W/ DURABLE
ADHESIVE;DWG.NO:04145;(R14-GX112-FOAM-REVA.DWG)
67 1.0000 PC BUSHING;CABLE;FS112;NYLON;DWG.NO:04141;(R14-
CABLEBUSHING-REVA.DWG)
*NOT available in DP
68 5.0000 PC F87-00100-13260 12AX7 GROMMET;P0806;DST.NO:001;DPT.NO:13260;(P0806-
12AX7_GROMMET-REVA.DWG)
(EU, UL, JP, UK, SAA, BR, AR,
HM, SH)
Ic
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC S60-54422-00528 C60-22422-00528 IC;AD/DA;V4220M;SSOP [BDM2:00: {1.0}(IC2)]
2 1.0000 PC S73-58007-22208 C73-58007-22208 IC;OPAMP OPAMP;TL072;SOP;BRAND:ST ONLY [BDM2:00: {1.0}(IC5)]
3 1.0000 PC S77-00000-09882 C77-00000-09882 IC;VOLT.REGULATOR;TO220;3;NATIONAL SEMICONDUCTOR
LM7815CT
[P0803:01: {1.0}(IC3)]
4 1.0000 PC S77-05107-03110 C77-05107-03110 IC;VOLT.REGULATOR;7805F;FULLPACK;TO220 [BDM2:00: {1.0}(IC1)]
5 1.0000 PC T12-00100-02216 D12-00100-02217 IC;DIG COMM.;EUROTEC;V1000;SOIC [BDM2:00: {1.0}(IC3)]
6 1.0000 PC T22-31001-40514 D22-31001-40514 IC;LOGIC;74HC14;SOP [P0803:01: {1.0}(IC1)]
7 1.0000 PC T22-31007-40514 D22-31007-40514 IC;LOGIC;74HC74;SOP [P0803:01: {1.0}(IC2)]
8 1.0000 PC T24-48030-02803 D24-48030-02803 IC;MICROCONTROLLER;MAX809STRG;Vth:2.93V;SOT [BDM2:00: {1.0}(IC4)]
Led
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC U10-51610-05431 E10-51610-05431 LED HIB;3mm ROUND;AMBER;VERTICAL;NO RING;WAVELENGTH:610
nm
[P0803:01: {1.0}(LD1)]
2 1.0000 PC U10-53565-00588 E10-53565-00588 LED HIB;3mm ROUND;GREEN [P0A5I:00: {1.0}(LD2)]
3 1.0000 PC U12-57630-00590 E12-57630-00590 LED;3mm ROUND;RD [P0A5I:00: {1.0}(LD1)]
