Bugera V22 - Page 9

Parts ListV22
Page 9
Cable
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC A81-15000-26042 WIRE HARNESS;LENGTH:150mm;AWG:26;POLES:2;HOUSING -
BOARD IN CONNECTOR;P:2mm;PIN1 RED/OTHERS BLK
2 1.0000 PC A81-15000-26842 WIRE
HARNESS;LENGTH:150mm;ZEE;AWG:26;UL2468;POLES:2;HOUSING -
BOARD IN CONNECTOR;P:2mm;PIN1 RD/OTHERS BK
[P0803:01: {1.0}(PCB112)]
3 1.0000 PC A81-18070-32023 WIRE HARNESS;LENGTH:180mm;POLES:3;AWG:18;UL1015;ONE SIDE
5mm STRIP/TINNED;PIN2 HAVE NO CONNECTION
4 1.0000 PC A81-18070-32823 WIRE HARNESS;LENGTH:180mm;ZEE;POLES:3;AWG:18;UL1015;ONE
SIDE 7mm STRIP/TINNED;PIN2 HAVE NO CONNECTION
5 1.0000 PC A81-18170-52023 WIRE HARNESS;LENGTH:180mm;POLES:5;AWG18;UL1015;ONE SIDE
2*5mm+12mm STRIP/TINNED;PIN2 AND PIN4 HAVE NO
CONNECTION
6 1.0000 PC A81-18170-52823 WIRE HARNESS;LENGTH:180mm;ZEE;POLES:5;AWG18;UL1015;ONE
SIDE 2*7mm+12mm STRIP/TINNED;PIN2 AND PIN4 HAVE NO
CONNECTION
7 1.0000 PC A81-19030-36045 WIRE HARNESS;LENGTH:190mm;AWG:26;P:2mm;HOUSING-BOARD
IN CONNECTOR;POLES:3;A2006H;PIN1 RED/OTHERS BLK
8 1.0000 PC A81-19030-36845 WIRE
HARNESS;LENGTH:190mm;ZEE;AWG:26;UL2468;P:2mm;HOUSING-
BOARD IN CONNECTOR;POLES:3;A2006H;PIN1 RD/OTHERS BK
[P0803:01: {1.0}(PCB129)]
9 1.0000 PC A81-27070-22022 WIRE HARNESS;LENGTH:270mm;POLES:2;AWG:18;UL1015;ONE SIDE
5mm STRIP/TINNED;PIN1 RED/OTHERS BLK
10 1.0000 PC A81-27070-22822 WIRE HARNESS;LENGTH:270mm;ZEE;POLES:2;AWG:18;UL1015;ONE
SIDE 7mm STRIP/TINNED;PIN1 RD/OTHERS BK
11 1.0000 PC A81-45000-46042 WIRE HARNESS;LENGTH:450mm;AWG:26;P:2mm;HOUSING-BOARD
IN CONNECTOR;POLES:4;PIN1 RED/OTHERS BLK;PIN 2 IS SHIELDED
[P0803:01: {1.0}(PCB130)]
12 1.0000 PC A81-45000-46842 WIRE HARNESS;LENGTH:450mm;ZEE;AWG:26;P:2mm;HOUSING-
BOARD IN CONNECTOR;POLES:4;PIN1 RED/OTHERS BLK;PIN 2 IS
SHIELDED
[P0803:01: {1.0}(PCB130)]
13 1.0000 PC Q88-45002-03732 A88-45002-03732 CABLE;SPEAKER;P0667;LENGTH:450mm;AWG:18;UL1015;6mm35
MONO JACK CONNECTOR ANGLED/2-5.2mm AMP LOCK
TAPE;COLOR:BLACK/RED
14 1.0000 PC Q89-50031-04316 A89-50031-04316 FOOTSWITCH
CABLE;FS112;LENGTH:5000mm;POLES:3;COLOR:BLK;SPEC.NO:04316
15 1.0000 PC Q76-15042-05624 A76-15042-05624 CABLE;AC-CORD;W/POLYBAG;LENGTH:150cm;H05VV-
F3G0.75MM2;VERSION;UK;SPEC.NO:05624
(UK)
16 1.0000 PC Q76-00000-05305 A76-00000-05305 CABLE;AC-CORD;3;BR;1500 MM;Plug + Connector:375+730;H05VV-F
3G0.75
(BR)
17 1.0000 PC Q76-15212-03119 A76-15212-03119 CABLE;AC-CORD;W/POLYBAG;LENGTH:152cm;H05VV-F 3G
0.75MM2;VERSION;EU;SPEC.NO:03119
(EU, RU)
18 1.0000 PC Q76-15222-06417 A76-15222-06417 CABLE;AC-
CORD;W/POLYBAG;LENGTH:152cm;AWG:18;VERSION;UL;SPEC.NO:0
6417
(UL)
19 1.0000 PC Q76-15032-55649 A76-15032-55649 CABLE;AC-CORD;CLASS
II;W/POLYBAG;JAPAN;LENGTH:150cm;POLES:3;APPROVAL:PSE;JS15S
3 + VCTF 3x0.75mm2 + V1528
(JP, HM, SH)
20 1.0000 PC Q76-00000-13573 A76-00000-13573 CABLE;AC-CORD;3;AR;1500 MM;Plug + Connector:321+730;H05VV-F
3G0.75
(AR)
21 0.0000 PC A76-18050-06505 CABLE;AC-CORD;LENGTH:180cm;VERSION:SAA;PLUG:HE105
ISOLATED;SAA H05VV-F 3x0.75mm2;CONN.HP-3;PANYU
(SAA)
22 1.0000 PC Q76-18050-47490 A76-18050-47490 CABLE;AC-CORD;LENGTH:180cm;VERSION:SAA;PLUG:HE105
ISOLATED;SAA H05VV-F 3x0.75mm2;CONN.HP-3;SPEC.NO:47490
(SAA)
