6-39
NOTICE:
Do not cover a headlamp to improve beam
cut
-off when aiming. Covering a headlamp may
cause excessive heat build
-up which may cause
damage to the headlamp.
5. Turn the vertical
aiming screw (C)
until the headlamp
beam is aimed to
the horizontal
tape line.
The top edge of the cut
-off should be positioned at
the bottom edge of the horizontal tape line.
6. Repeat steps 4 and 5 for the opposite headlamp.
