6-66
Maxibreaker Usage
41 Starter
MaxiFuses Usage
42 A.I.R.
43 Empty
44 ABS
45 Not Used
46 Cooling Fan 2
47 Cooling Fan 1
Spare Fuses Usage
48 Spare
49 Spare
50 Spare
51 Spare
52 Spare
53 Fuse Puller
Removing the Rear Seat Cushion
NOTICE:
The battery and main fuse blocks are located
under the rear seat cushion. The battery’s ground
terminal and some relay wires are exposed.
To help avoid damage to the battery and wires,
be careful when removing or reinstalling the
seat cushion. Do not remove covers from covered
parts. Do not store anything under the seat,
as objects could touch exposed wires and cause
a short.
To remove the rear seat cushion, do the following:
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front of
the vehicle.
