7. Turn the bulb socket
one-quarter turn
counterclockwise, while
pressing it firmly.
8. Pull the bulb socket straight out of the assembly.
9. Remove the old bulb by pulling it straight out.
10. Replace with a new bulb by pushing the bulb
straight into the socket until the bulb clicks
into place.
11. Turn the bulb socket one-quarter turn into the
assembly to lock it back into place.
12. Reverse Steps 1 through 5 to reinstall the
lamp assembly.
Taillamps and Back-Up Lamps
1. Open the trunk. See Trunk on page 2-14 for
more information.
2. Loosen and remove the seven fasteners that hold
the taillamp assembly in place. The assembly for
both sides is one piece. The entire piece must
be removed to replace any bulbs.
5-51
