Buick 2011 Lacrosse - Replacement Bulbs

Black plate (36,1)
Buick LaCrosse Owner Manual - 2011
10-36 Vehicle Care
A. Bulb Socket
B. Bulb
C. Lamp Assembly
3. Turn the bulb socket (A)
counterclockwise to remove from
lamp assembly (C).
4. Pull the bulb (B) straight out of
the bulb socket.
5. Push the replacement bulb
straight into the bulb socket and
turn the bulb socket clockwise to
install into lamp assembly.
6. Move the lamp assembly into
the trunk lid engaging the clip
side first.
7. Push on the lamp side opposite
the clip until the lamp assembly
snaps into place.
Replacement Bulbs
Exterior Lamp
Bulb
Number
Back-Up Lamp W16WLL
Daytime Running
Lamp (Up-Level)
3157K LCP
Front Turn Signal/
Park Lamp
3757NAK
LCP
Headlamp High
Beam (Base)
H9
Headlamp Low
Beam (Base)
H11LL
License Plate Lamp W5WLL
Rear Turn Signal
3757AK
LCP
For replacement bulbs not listed
here, contact your dealer.
