Black plate (33,1)

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

6042574) - 2014 - CRC - 5/28/13

Vehicle Care 10-33

Mini

Fuses

Amps Usage

1 20A Engine

Control

Module

2 10A Oxygen

Sensor/Purge

Solenoid

3 15A Ignition Coils/

Injectors

4 15A Spare

5 – Empty

6a – Empty

6b 7.5A Mirror

Defogger

7 5A Powertrain

Cooling

8 7.5A Mass Air

Flow Sensor/

Pre O2

Sensor

9 – Empty

Mini

Fuses

Amps Usage

10 5A Battery

Potential

Signal

11 7.5A Spare

12 – Empty

13 25A Antilock

Brake

System

Valves

14 – Empty

15 10A Engine

Control

Module

17 10A Transmission

Control

Module

22 – Empty

24 15A Right

High-Beam

Headlamp

Mini

Fuses

Amps Usage

25 15A Left

High-Beam

Headlamp

26 15A Front Fog

Lamps

31 – Empty

32 5A Airbag

33 – Empty

34 7.5A Spare

35 7.5A Door Switch

Supply/Left

Power

Window

36 10A Air

Conditioning

Compressor

Clutch

37 10A Canister Vent

38 – Empty
